Shop RED LION CONTROLS

Counter, LCD, 8 Digits, 1.86" D

  • Mfr # CUB5R000

  • Zoro # G805386306

product price:  $247.99
/ea
Free Shipping & Returns

Key Features

Mounting
Panel
Reset Type
Push Button
Display
LCD
Number of Digits
8
Connector Type
Wire Clamp/Screw Terminal
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
CUB5R000
Zoro #
G805386306
UPC #
-
Country of Origin
United States

Dimensions

Character Height
0.46 in
Width
2.95 in
Height
1.54 in
Depth
1.86 in
Overall Width
3 in
Cutout Height
1 3/8 in
Overall Depth
1 7/8 in
Overall Height
1 1/2 in
Digit Height - Maximum
0.46 in
Cutout Width
2 3/4 in

Details

Item
Counter
Mounting
Panel
Reset Type
Push Button
Display
LCD
Number of Digits
8
Connector Type
Wire Clamp/Screw Terminal
Includes
Mounting Clip, Panel Gasket
Standards
CE Approved, cULus, UKCA
Input Signal
9 to 28VDC Current Sinking and Current Sourcing
Accuracy
+/-0.01%
Max. Counts per Second
1
Min. On/Off Pulse
50 msec
Scaler
Yes
Preset
Yes
Power Required
9 to 28 V DC
IP Rating
IP65
Fits
2.68 in x 1.3 in Panel Cutout
Prescaling Range
0 to 999,999
NEMA Rating
4X
Special Features
Decimal Points and Scaling, Dual Counter or Counter/Rate Indicator, Front Panel Programming, Preset Capability
Interface
RS-232, RS-485
Input Voltage
10 to 28V DC
Output Type
Relay
Counts per Second - Maximum
1
Counter Display Type
LCD
NEMA Enclosure Rating
4X
Mounting Style
Panel
Terminal Connection Type
Wire Clamping Screw
Features
Decimal Points and Scaling, Dual Counter or Counter/Rate Indicator, Front Panel Programming, Optional Setpoint Cards available (Dual Sink or Relay), Optional USB Programming Card Available, Preset Capability with Optional Output Card
Includes Mounting Hardware
Included
Count Speed - Maximum
20 kHz
Digit Color
Green/Red

Description

Counter, Number of Digits 8, LCD Display, Character Height 0.46 in, Max. Counts per Second 1, Input Signal 9 to 28VDC Current Sinking and Current Sourcing, Output Rating Not Applicable, Mounting Panel, Height 1.54 in, Depth 1.86 in, Width 2.95 in, Scaler Yes, Preset Yes, Power Required 9 to 28 V DC, Min. On/Off Pulse 50 msec, Prescaling Range 0 to 999,999, Reset Type Push Button, Interface RS-232, RS-485, Connector Type Wire Clamp/Screw Terminal
