Shop RESIDEO

Thermostat

  • Mfr # TH2320WF4010/U
  • Zoro # G222784068
product price:
$
100.99
/ea
Free Shipping & Returns

Key Features

Electrical Connection Type
Hardwired
Voltage
24V AC
Backlit Screen
Yes
Backlit Type
Always On
Maximum Operating Temperature
120 Degrees F
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
TH2320WF4010/U
Zoro #
G222784068
UPC #
194159017467
Country of Origin
Mexico
Electrical Connection Type
Hardwired
Voltage
24V AC
Backlit Screen
Yes
Backlit Type
Always On
Maximum Operating Temperature
120 Degrees F
Minimum Operating Humidity
5 %
Frequency
60 Hz
Compatible System Type
24V AC Heat and Cool Systems, Heat pumps with Auxiliary Heat, Steam/Radiant Hot Water Systems
Humidification Control
No
Number of Cooling Stages - Conventional System
2
Maximum Control Temperature
99 Degrees F
Changeover Type
Automatic and Manual
Includes Positive Off
Yes
Shape
Rectangle
Mounting Direction
Horizontal
Item
Low Voltage Programmable Thermostat
Maximum Operating Humidity
90 %
Programming Capability
5-1-1, 5-2, 7-Day
Temperature Control Range
32 Degrees to 90 Degrees F (Heat), 50 Degrees to 99 Degrees F (Cool)
Number of Cooling Stages - Heat Pump System
2
Number of Heating Stages - Heat Pump System
3
Filter Change Reminder
Yes
Operating Humidity Range
5% to 90% RH
Application
Heat and Cool
System Settings
Auto-Heat-Cool-Off, Emergency Heat
Operating Temperature Range
32 Degrees to 120 Degrees F
Number of Heating Stages - Conventional System
2
Fan Settings
Auto, Cool, Emergency Heat, Heat, Off
Dehumidification Control
No
Temperature Scale
Fahrenheit/Celsius
Housing Color
White
Temperature Sensitivity
1 Degrees F
Product Type
Programmable Thermostat
Minimum Control Temperature
32 Degrees F
Control Type
Push Button
Display Type
Digital
Minimum Operating Temperature
32 Degrees F
Includes
Decorative Cover Plate with J-Box Adapter, Mounting Hardware, Thermostat, UWP Mounting Plate
Thermostat Type
Digital, Programmable

Dimensions

Overall Depth
1 3/16 in
Overall Height
3 7/16 in
Overall Width
5 1/8 in

Description

Low Voltage Programmable Thermostat, Display Type Digital, Key Pad Lockout Not Applicable, Humidification Control No, Dehumidification Control No, Voltage 24V AC, Mounting Location Wall, Includes Decorative Cover Plate with J-Box Adapter, Mounting Hardware, Thermostat, UWP Mounting Plate
