Both Electric Tankless Water Heater, General Purpose, 59 Degrees to 140 Degrees F, 208/240VAC

  • Mfr # RTEX-18

  • Zoro # G8038880


product price:  $545.99
/ea
Free Shipping & Returns

Key Features

Water Heater Design
Whole House
Voltage - Water Heaters
208/240
Amps - Water Heaters
75
Phase - Water Heaters
1
Temp. Range - Water Heaters
59 Degrees to 140 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
RTEX-18
Zoro #
G8038880
UPC #
020352685335
Country of Origin
China

Dimensions

Height
18-1/4"
Depth
3-1/2"
Height to Top of Vent Connection
18.25"
Height to Top of Heater
18.25"
Width
14-1/2"
Wire Size
8 AWG
Overall Width
8.25 in
Overall Height
18.25 in
Overall Depth
3.5 in
Manufacturer Warranty Length
1 yr Limited Parts, 5 yr Heating Chamber
Cold Inlet Size
3/4 in

Details

Water Heater Design
Whole House
Voltage - Water Heaters
208/240
Watts - Water Heaters
18,000
Amps - Water Heaters
75
Phase - Water Heaters
1
Temp. Range - Water Heaters
59 Degrees to 140 Degrees F
Min. Flow Activation
0.30 gpm
Water Heater Application
General Purpose
Commercial / Residential
Both
Item
Electric Tankless Water Heater
Standards
cETLus Intertek, CSA C22.2 No.64, No Lead Compliant, NSF/ANSI 372, UL 499, WQA Certified
Amps AC
75
Default Temperature
120 Degrees F
Temp. Rise @ 6.0 GPM
Limited to Thermostatic Setting
Item - Water Heaters
Electric Tankless Water Heater
Phase
single
Tank Capacity
18 gal.
Max. Flow Rate
4 gpm
Elements
Lead-Free Replaceable Cartridge Insert
Fuel Type
Electric
Temp. Range
59 Degrees to 140 Degrees F
Water Connection
3/4" NPT
Voltage
208/240VAC
Residential / Commercial
Both
Mounting
Wall
Vent Type
Tankless Electric
Pressure Range
25 to 150 psi
Temp. Rise @ 4.0 GPM
31 Degrees F
Temp. Rise @ 2.5 GPM - Water Heaters
49 Degrees F
Features
Endless Hot Water, Replaceable Heating Element, Adjustable Digital Temperature Display
Temp. Rise @ 2.5 GPM
49 Degrees F
Environment
Indoor
Element Material
Copper
Maximum Delivered Temperature
140 Degrees F
Current
75 A
Minimum Water Pressure
25 psi
Adjustable Thermostat
Yes
Minimum Flow Activation
0.3 gpm
Cord Conductor Gauge
8 AWG Wire
Water Connection Location
Bottom
Control Type
Dial, Digital Display with Keypad
Minimum Delivered Temperature
80 Degrees F
Maximum Water Pressure
150 psi
Power Consumption
18,000 W
Temperature Rise @ Flow
40 Degrees F @ 2 gph, 50 Degrees F @ 2 gph, 60 Degrees F @ 2 gph, 70 Degrees F @ 3 gph
Market
Residential
Mounting Type
Wall Mounting
Maximum Flow Rate
4.4 gpm
Operating Voltage
240V AC

Description

Electric Tankless Water Heater, Operating Voltage 240V AC, Phase Single, Cold Inlet Size 3/4 in, Maximum Flow Rate 4.4 gpm, Minimum Flow Activation 0.3 gpm, Overall Depth 3.5 in, Overall Height 18.25 in, Overall Width 8.25 in, Power Consumption 18,000 W, Maximum Delivered Temperature 140 Degrees F, Minimum Delivered Temperature 80 Degrees F, Adjustable Thermostat Yes, Current 75 A, Environment Indoor, Market Residential, Control Type Dial, Digital Display with Keypad
