Axial Fan, Gray, 12-11/16 in H
Mfr # 3245510
Zoro # G222440070
product price:Â
$
1,219.99
/ea
Free Shipping & Returns
Key Features
Bearing Protection
Sealed
Height
12 11/16 in
Mounting Position
Vertical
Bearing Type
Ball
Standards
30-KC Korea, CSA, UL and C-UL Recognized, UR and C-UR Recognized
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 3245510
- Zoro #
- G222440070
- UPC #
- 639889869035
- Country of Origin
- Germany
Dimensions
- Height
- 12 11/16 in
- Width
- 12 11/16 in
Details
- Bearing Protection
- Sealed
- Mounting Position
- Vertical
- Bearing Type
- Ball
- Standards
- 30-KC Korea, CSA, UL and C-UL Recognized, UR and C-UR Recognized
- Amps
- 2.1 A
- Item
- Axial Fan
- Hz
- 60/50 Hz
- IP Rating
- IP56
- Includes Filter
- Yes
- CFM @ 0.000-In. SP
- 523.8 cfm, 662.2 cfm
- Sound Level
- 72 dBA
- Voltage
- 100/130V AC
- Includes
- Chopped Fiber Filter Mat
- Color
- Gray
- Watts
- 165 W
- Max. Ambient Temp.
- 131 Degrees F
Description
Axial Fan, Height 12 11/16 in, Diameter Not Applicable, Width 12 11/16 in, CFM @ 0.000-In. SP 523.8 cfm, 662.2 cfm, Watts 165 W, Voltage 100/130V AC, 60/50 Hz Hz, 2.1 A Amps, Sound Level 72 dBA, IP Rating IP56, Fan Mounting Location Wall, Mounting Position Vertical, Bearing Type Ball, Motor Design ECM, Max. Ambient Temp. 131 Degrees F, Color Gray, Includes Chopped Fiber Filter Mat, Standards 30-KC Korea, CSA, UL and C-UL Recognized, UR and C-UR Recognized
