Parallel Gripper
Mfr # DPL-4040
Zoro # G0093869
product price: $4,467.99
/ea
Free Shipping & Returns
Key Features
Overall Length
3 1/4 in
Overall Width
9 3/8 in
Weight
9.48 lb
Overall Height
4 3/8 in
Product Type
Parallel Gripper
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
DPL-4040
Zoro #
G0093869
UPC #
-
Country of Origin
France
Dimensions
Overall Length
3 1/4 in
Overall Width
9 3/8 in
Overall Height
4 3/8 in
Maximum Finger/Jaw Length
13 3/4 in
Inlet Size
1/8 in
Stroke Length
3 1/8 in
Details
Item
Parallel Gripper
Weight
9.48 lb
Product Type
Parallel Gripper
Operation Type
Synchronous
Accuracy
+/-0.003 in
Series
DPL
Maximum Operating Pressure
100 psi
Maximum Operating Temperature
180 Degrees F
Maximum Actuation Time
0.5 sec
Minimum Operating Pressure
30 psi
Air Inlet Type
BSPP
System of Measurement
Inch
Total Rated Grip Force @ 100 psi
2,028.38 N
IP Rating
IP54
Displacement
36.05 cc
Repeatability
+/-0.001 in
Minimum Operating Temperature
-4 Degrees F
Description
Parallel Gripper, Series DPL, Stroke Length 3 1/8 in, Maximum Operating Pressure 100 psi, Minimum Operating Pressure 30 psi, Overall Length 3 1/4 in, Overall Width 9 3/8 in, Overall Height 4 3/8 in, Inlet Size 1/8 in, Air Inlet Type BSPP, Maximum Operating Temperature 180 Degrees F, Minimum Operating Temperature -4 Degrees F, Weight 9.48 lb, System of Measurement Inch, Total Rated Grip Force @ 100 psi 2,028.38 N, IP Rating IP54, Displacement 36.05 cc, Accuracy +/-0.003 in
