  11. Rigid Shaft Coupling, Set Screw, 8mm
Ruland Rigid Shaft Coupling, Set Screw, 8mm MSCC-8-8-F - main

Rigid Shaft Coupling, Set Screw, 8mm

  • Mfr # MSCC-8-8-F

  • Zoro # G8071296

product price: $33.45
/ea

Key Features

Shaft Locking Type - Couplings
1 Piece Set Screw
System of Measurement
Metric
Material - Couplings
1215 Lead Free Steel
Outside Dia.
24 mm
Overall Length
35 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
MSCC-8-8-F
Zoro #
G8071296
UPC #
634529076507
Country of Origin
United States

Dimensions

Bore Dia.
8 mm
Outside Dia.
24 mm
Overall Length
35 mm
Keyway Width
2 mm
Keyway Width (mm)
2
Screw Size (mm)
M4
Screw Size
M4
Keyway Depth 1
1.1 mm
Different Bore Sizes
No
Coupling Outside Diameter
24 mm
Maximum Bore Diameter
8 mm
Clearance Diameter
24 mm
Keyway Width 1
2 mm
Bore Diameter 2
8 mm
Keyway Depth 2
1.1 mm
Screw Thread Size
M4
Keyway Width 2
2 mm
Minimum Bore Diameter
8 mm
Bore Diameter 1
8 mm

Details

Shaft Locking Type - Couplings
1 Piece Set Screw
Item
Rigid Shaft Coupling
System of Measurement
Metric
Material - Couplings
1215 Lead Free Steel
With Keyway / Without Keyway
With Keyway
Finish
black oxide
Design
Precision Honed Bores On Straight Bore Rigid Couplings, Anti-Vibration Coating Used On Hardware, Bore Tolerance of +.002"/.0005" (+.050mm/+.012mm), Machined From Solid Bar Stock and Sourced Exclusively from North American Mills
Material
1215 Lead Free Steel
Max. RPM
4,000 RPM
Application
Zero Backlash Coupling That is Well Suited for Precise Servo Applications and Shaft to Shaft Connections with No Misalignment
Provides
High Torque with No Misalignment Capabilities
Type
Set Screw Type, with Keyway
Item - Rigid Shaft Couplings
Rigid Shaft Coupling
Machined From
Bar Stock
Standards
Conflict Minerals Compliant, DIN 912 12.9 Screws, REACH Compliant, RoHS3 Compliant
Bore Tolerance
+0.050 mm / +0.012 mm
Screw Material
Alloy Steel
Resistance Properties
Corrosion Resistant
Fastener Tightening Torque
2.2 N-m
Bore Type
Round Keyed
Coupling Material Grade
1215
Coupling Material Finish
Black Oxide
Coupling Construction
One-Piece
Included Screws
(4) Set Screws
Minimum Operating Temperature
-40 Degrees C
Screw Material Finish
Black Oxide
Features
Precision Honed Bores, Vibration-Resistant Screws
Shaft Tolerance
+0.000 mm / -0.013 mm
Coupling Material
Carbon Steel
Maximum Operating Temperature
176 Degrees C
Shaft Locking Type
Set Screw
Maximum Speed
4,000 RPM
Maximum Torque
50 N-m
Number of Locking Screws
4
Zero Backlash
Yes

Description

Rigid Shaft Coupling, Bore Diameter 1 8 mm, Bore Diameter 2 8 mm, Bore Type Round Keyed, Clearance Diameter 24 mm, Coupling Construction One-Piece, Coupling Material Carbon Steel, Coupling Outside Diameter 24 mm, Different Bore Sizes No, Keyway Depth 1 1.1 mm, Keyway Depth 2 1.1 mm, Minimum Bore Diameter 8 mm, Keyway Width 1 2 mm, Keyway Width 2 2 mm, Maximum Bore Diameter 8 mm, Maximum Speed 4,000 RPM, Maximum Torque 50 N-m, Overall Length 35 mm, Shaft Locking Type Set Screw
