Shaft Collar, Alloy Steel, 2-Piece, 54 mm

  • Mfr # MSP-54-A

  • Zoro # G908672108

product price:  $42.39
/ea

Key Features

Screw Material
Alloy Steel
Width Tolerance
+0.076/-0.254 mm
System of Measurement
Metric
Bore Tolerance
+0.050/+0.012 mm
Standards
Conflict Minerals Compliant, DIN 912 12.9, ISO 9001:2015 Certified, REACH Compliant, RoHS3 Compliant
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
MSP-54-A
Zoro #
G908672108
UPC #
-
Country of Origin
United States

Dimensions

Width Tolerance
+0.076/-0.254 mm
For Shaft Diameter
54 mm
Collar Outside Diameter
82 mm
Bore Diameter
54 mm
Clearance Diameter
88.8 mm
Collar Width
19 mm
Screw Thread Size
M8x25
Screw Length
25 mm
Screw Size
M8 x 25
Bore Dia.
54 mm
Outside Dia.
82 mm
Clearance Dia.
88.8 mm
Width
19 mm

Details

Screw Material
Alloy Steel
Item
Shaft Collar
System of Measurement
Metric
Bore Tolerance
+0.050/+0.012 mm
Standards
Conflict Minerals Compliant, DIN 912 12.9, ISO 9001:2015 Certified, REACH Compliant, RoHS3 Compliant
Screw Seating Torque
39 N-m
Maximum Operating Temperature
225 Degrees F
Screw Location from Center
34.24 mm
Bore Type
Round
Minimum Operating Temperature
-40 Degrees F
Shaft Locking Type
Clamp-On
Included Screws
(2) Clamp Screw
Collar Construction
2-Piece
Screw Material Finish
Black Oxide
Collar Material
Aluminum
Collar Material Grade
2024
Shaft Tolerance
+0.000/-0.013 mm
Collar Material Finish
Bright
Recommended Shaft Tolerance
+0.000 mm / -0.013 mm
Screw Finish
Black Oxide
Weight
0.4171 lbs
Screw Location (R)
34.24 mm
Number of Screws
2
Finish
Bright, No Plating
Number of Pieces
2
Collar Style
Clamp
Material
2024-T351 Aluminum
Operating Temp. Range
-40 Degrees to 225 Degrees F

Description

Shaft Collar, System of Measurement Metric, Bore Type Round, Bore Diameter 54 mm, Bore Thread Size Not Applicable, Collar Outside Diameter 82 mm, Inside Height to Flat Not Applicable, Clearance Diameter 88.8 mm, Collar Width 19 mm, Collar Material Aluminum, Keyway Width Not Applicable, Collar Material Grade 2024, Keyway Depth Not Applicable, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 2-Piece, Screw Material Alloy Steel
