Shop RULAND

Shaft Collar, Clamp, 2Pc, 2 In, Alum

  • Mfr # SPK-32-A

  • Zoro # G8002723

product price:  $43.49
/ea

Key Features

Number of Pieces
2
Collar Style
Clamp Style with Keyway
Screw Size
5/16"-24
Operating Temp. Range
-40 Degrees to 225 Degrees F
Screw Material
Alloy Steel
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
SPK-32-A
Zoro #
G8002723
UPC #
634529119518
Country of Origin
United States

Dimensions

Screw Size
5/16"-24
Width Tolerance
+0.003/-0.010 in
Collar Width
11/16 in
Bore Diameter
2 in
Screw Thread Size
5/16"-24
Collar Outside Diameter
3 in
Keyway Width
1/2 in
Clearance Diameter
3.27 in
Keyway Depth
1/4 in
For Shaft Diameter
2 in

Details

Number of Pieces
2
Collar Style
Clamp Style with Keyway
Operating Temp. Range
-40 Degrees to 225 Degrees F
Screw Material
Alloy Steel
Item
Shaft Collar
System of Measurement
Inch
Standards
ANSI, Conflict Minerals Compliant, ISO 9001:2015, REACH Compliant, RoHS Compliant
Bore Tolerance
+0.002/+0.0005 in
Screw Seating Torque
325 lb-in
Collar Material
2024 Aluminum
Bore Type
Round Keyed
Minimum Operating Temperature
-40 Degrees F
Maximum Operating Temperature
225 Degrees F
Collar Construction
2 Piece Clamp with Keyway
Shaft Tolerance
+0.0000/-0.0005 in
Collar Material Finish
Bright
Shaft Locking Type
Clamp-On
Screw Material Finish
Black Oxide
Screw Location from Center
1.25 in
Collar Material Grade
2024
Included Screws
(2) Hex Socket Cap Screw
Number of Screws
2
Weight
0.271 lbs

Description

Shaft Collar, System of Measurement Inch, Bore Type Round Keyed, Bore Diameter 2 in, Bore Thread Size Not Applicable, Collar Outside Diameter 3 in, Inside Height to Flat Not Applicable, Clearance Diameter 3.27 in, Collar Width 11/16 in, Collar Material Aluminum, Keyway Width 1/2 in, Collar Material Grade 2024, Keyway Depth 1/4 in, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 2-Piece, Screw Material Alloy Steel, Screw Material Finish Black Oxide

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
