  11. Swivel Plate Caster, Nylon, 8 in., 1800 lb.
Rwm Swivel Plate Caster, Nylon, 8 in., 1800 lb. 68-GTB-0820-S - main

Swivel Plate Caster, Nylon, 8 in., 1800 lb.

  • Mfr # 68-GTB-0820-S

  • Zoro # G7000542

product price: $235.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Swivel
Wheel/Tread Material
Elastomer
Caster Brake Type
No Brake
Wheel Dia.
8 in
Wheel Width
2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
68-GTB-0820-S
Zoro #
G7000542
UPC #
-
Country of Origin
United States

Dimensions

Wheel Dia.
8 in
Wheel Width
2 in
Mounting Height
10 1/8 in
Mounting Plate Size
4 1/2 in x 6 1/2 in
Mounting Plate Thickness
1/4in
Mounting Bolt Dia.
1/2 in
Stem Dia.
No Stem
Overall Height
10-1/8in

Details

Item
Plate Caster
Caster Sub-Type
Swivel
Wheel/Tread Material
Elastomer
Caster Brake Type
No Brake
Load Rating
1800 lb
Wheel Bearing Type
Ball
Wheel/Tread Color
Blue
Wheel Hardness Rating
75 Shore D
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Gray
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Inside Bolt Hole Spacing
2-7/16 in x 4-15/16 in
Caster Plate Hole Pattern
B
Extended Lead
No
Caster Stem Type
No Stem/Plate Included
Application
Dollies, Platform Trucks, Tow Lines
Wheel Color
Blue
Features
Maintenance Free
Frame Finish
Zinc Plated
Includes
Complete Caster
Thread Guards
No
Standards
ANSI ICWM, ISO 9001:2015
Replacement Wheel
Mfr. No. GTB-0820-08
Caster Temp. Range Available
Yes
Caster Brake Included
No
Swivel Raceway Type
Double/Single Ball
Load Rating Range
1000 to 2999 lb
Swivel Construction
Kingpin
Wheel/Tread Hardness Rating
Hard
Wheel Core Material
Rubber
Swivel Lock Type
No Lock Included
Includes Thread Guards
No
Load Capacity - Maximum
1,800 lb
Compatible With
GTB-0820-08
Caster Features
Maintenance Free
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
275 Degrees F
Operating Temperature Range
-40 Degrees to 275 Degrees F

Description

Swivel, Plate Caster, Load Rating 1800 lb, Swivel Lock Type No Lock Included, Wheel Dia. 8 in, Wheel Width 2 in, Wheel/Tread Material Elastomer, Wheel Core Material Rubber, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
