- MFR #
- PM040 LATD 622
- Zoro #
- G823524902
- UPC #
- 197163385690
- Country of Origin
- Mexico
- Visual Indicator Location
- Inside/Outside
- Lockset Function ANSI Code
- F22
- Voltage
- 12/24V DC
- Fire Rating
- 3 hr
- Standards
- ANSI/BHMA A156.13-2017, CAN/ULC-S104, ICC A117.1, UL 437 Listed
- Performance Grade
- 1
- Includes Core
- Core Included
- Knob/Handle Material
- Zinc
- ANSI/BHMA Finish
- Black Painted
- Lockset Style
- Latitude
- Item
- Door Lockset
- Number of Keys
- 0
- Hand Orientation
- Non-Handed
- Lockset Type
- Mechanical
- Mortise/Cylindrical
- Mortise
- Features
Breakaway Spindle Keeps Door Secured in the Event of Vandalism, Two Piece Anti-Friction Tongue in Latch Bolt Reduces Wear, Every Schlage Lock Undergoes Intensive Testing to Determine its ANSI Grade Level Including: Cycle, Resistance, Door Impact, Warped Door and Bolt Strength Tests, Extensive Cylinder Support for Schlage and 7 Non-Schlage Formats, Field Reversible Latch Bolt Allows Handing Change without Opening Case, Lock Status Indication for Sectional Trims (Available on Most Functions) uses Red and White Backgrounds to Ensure Quick Readability for Color Blind Individuals, Patented Everest 29(TM) S123 Keyway Provided Standard which Prohibits Unauthorized Key Duplication, Performance Series Exclusive Levers (Selena and Playa) and D Square Rose are Shared with the Pt Series(TM) Tubular Lock, Security Blocking Hub Prevents Lock Access by Removing Levers, Anti-Saw Pin in Bolt to Prevent Cut-Through
- Strike Type
- Curved Lip
- Failure Mode
- Fail Safe or Fail Secure
- Locking/Unlocking Access - Outside
- Thumb Turn
- Number of Pins
- 0
- Includes
- Dust Box
- Application
- Commercial Real Estate, Hospitality, Residential, Retail
- Backset
- 2 3/4 in
- Latch Bolt/Dead Bolt
- Latch Bolt
- Key Material
- Nickel Silver
- ADA Compliant
- Yes
- ANSI Grade
- 1
- Key Type
- Not Keyed
- Locking/Unlocking Access - Inside
- Not Lockable
- Keyway Type
- S123
- Ligature-Resistant
- Not Ligature-Resistant
- Visual Indicator Message
- No Message
