- MFR #
- PM453P LATA 622
- Zoro #
- G823525220
- UPC #
- 197163387175
- Country of Origin
- Mexico
- Latch Bolt/Dead Bolt
- Dead Bolt
- Hand Orientation
- Non-Handed
- Locking/Unlocking Access - Inside
- Thumb Turn
- Fire Rating
- 3 hr
- Lockset Type
- Mechanical
- Item
- Door Lockset
- Includes Core
- Core Included
- Number of Pins
- 6
- Key Material
- Nickel Silver
- Backset
- 2 3/4 in
- Keyway Type
- S123
- Lockset Style
- Latitude
- Strike Type
- Curved Lip
- Locking/Unlocking Access - Outside
- Keyway
- Visual Indicator Location
- Inside/Outside
- Voltage
- 12/24V DC
- ADA Compliant
- Yes
- Mortise/Cylindrical
- Mortise
- ANSI/BHMA Finish
- Black Painted
- Includes
- Dust Box
- Lockset Function ANSI Code
- F20
- Knob/Handle Material
- Zinc
- Application
- Commercial Real Estate, Hospitality, Residential, Retail
- Key Type
- Keyed Different
- Features
Breakaway Spindle Keeps Door Secured in the Event of Vandalism, Two Piece Anti-Friction Tongue in Latch Bolt Reduces Wear, Every Schlage Lock Undergoes Intensive Testing to Determine its ANSI Grade Level Including: Cycle, Resistance, Door Impact, Warped Door and Bolt Strength Tests, Extensive Cylinder Support for Schlage and 7 Non-Schlage Formats, Field Reversible Latch Bolt Allows Handing Change without Opening Case, Lock Status Indication for Sectional Trims (Available on Most Functions) uses Red and White Backgrounds to Ensure Quick Readability for Color Blind Individuals, Patented Everest 29(TM) S123 Keyway Provided Standard which Prohibits Unauthorized Key Duplication, Performance Series Exclusive Levers (Selena and Playa) and D Square Rose are Shared with the Pt Series(TM) Tubular Lock, Security Blocking Hub Prevents Lock Access by Removing Levers, Anti-Saw Pin in Bolt to Prevent Cut-Through
- Standards
- ANSI/BHMA A156.13-2017, CAN/ULC-S104, ICC A117.1, UL 437 Listed
- Performance Grade
- 1
- Failure Mode
- Fail Safe or Fail Secure
- ANSI Grade
- 1
- Visual Indicator Message
- No Message
- Cylinder Core Type
- Conventional Core Cylinder
- Ligature-Resistant
- Not Ligature-Resistant
