Schneider Electric 120VAC Reversing Magnetic Contactor 3P 18A NEMA 0 T02BN23G7 - main

120VAC Reversing Magnetic Contactor 3P 18A NEMA 0

  • Mfr # T02BN23G7

  • Zoro # G6060406

product price:  $494.99
/ea
Free Shipping & Returns

Key Features

Action
Reversing
Full Load Amps
18 A
Number of Poles
3
Coil Volts
120V AC
NEMA Contactor Size
0
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
T02BN23G7
Zoro #
G6060406
UPC #
785901514220
Country of Origin
France

Dimensions

NEMA Contactor Size
0
Height
3.9 in
Width
3.54 in
Depth
3.62 in
NEMA Size
0
Overall Height
3.71 in
Overall Depth
3.62 in
Overall Width
3.53 in

Details

Item
Magnetic Contactor
Action
Reversing
Full Load Amps
18 A
Number of Poles
3
Coil Volts
120V AC
Reversing
Yes
HP @ 1 Phase - 120V
1 hp
HP @ 1 Phase - 240V
2 hp
HP @ 3 Phase - 208V
3 hp
HP @ 3 Phase - 575V
5 hp
HP @ 3 Phase - 240V
3 hp
HP @ 3 Phase - 480V
5 hp
Enclosure NEMA Rating
No Enclosure
Hz
50/60
Frame / Series / Class / Code
TeSys
Standards
CSA, UL Listed
Auxiliary Contact Form
1NO/1NC
Series
TeSys N
Maximum Horse Power Rating
3 hp 200 V AC || 3 hp 230 V AC || 5 hp 460 V AC || 5 hp 575 V AC
Product Or Component Type
contactor
Line Rated Current
18 A
Auxiliary Contact Composition
1 NO + 1 NC
Contactor Application
reversing
[Ue] Rated Operational Voltage
600 V AC
Electrical Connection
screw clamp terminals
Nema Degree Of Protection
not rated (open device)
Poles Description
3P
[Uc] Control Circuit Voltage
120 V AC
Phase
Three
Product Certifications
UL Listed || CSA
Control Circuit
common control circuit
Coil Voltage
120V AC
Horsepower @ Three Phase - 240V AC
3 hp
Horsepower @ Single Phase - 120V AC
1 hp
Terminal Connection Type
Screw Clamp Terminals
Horsepower @ Single Phase - 240V AC
2 hp
Full Load Current - Inductive
18 A
Frequency
50/60 Hz
Contactor Style
NEMA
Embedded Surge Suppressor
No
Includes Auxiliary Contacts
Yes
Reversing Capability
Reversing
Horsepower @ Three Phase - 600V AC
5 hp
Number of Auxillary Contacts
2
Horsepower @ Three Phase - 480V AC
5 hp
NEMA Enclosure Rating
No Enclosure
Horsepower @ Three Phase - 208V AC
3 hp
Maximum Voltage Rating
600V AC

Description

NEMA Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size 0, Coil Voltage 120V AC, Number of Poles 3, Full Load Current - Inductive 18 A, Reversing Capability Reversing, Overall Height 3.71 in, Overall Width 3.53 in, Terminal Connection Type Screw Clamp Terminals, Series TeSys N, Number of Auxillary Contacts 2, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 3 hp, Horsepower @ Three Phase - 480V AC 5 hp, Phase Three
