  13. ControlStation, Dead-End, 1SelectSwtch, Blk
This item is Discontinued.
Schneider Electric ControlStation, Dead-End, 1SelectSwtch, Blk 9001KYSK111

ControlStation, Dead-End, 1SelectSwtch, Blk (Discontinued)

  • Mfr # 9001KYSK111
  • Zoro # G0196070
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001KYSK111
Zoro #
G0196070
UPC #
785901040071
Country of Origin
Mexico

Dimensions

Size
30 mm
Overall Depth
3.62 in
Manufacturer Warranty Length
18 mo
Panel Cutout Diameter
30 mm
Hub Size - Maximum
3/4 in
Overall Height
4.45 in
Overall Width
4.17 in

Details

Item
Control Station
Number of Gangs
1
Contact Form
1NO/1NC
Legend
Hand/Off/Auto
Number of Pilot Lights
0
Type of Operator
Selector Switch
Number of Operators
1
NEMA Rating
1, 13, 3, 4
Series
9001K
Hub Style
Dead-End
For Use With
indoor/outdoor
Standards
UL Listed
Contact Rating
10A @ 300V
Action
Maintained/Maintained/Maintained
Mechanical Interlock
No
Enclosure Material
Stainless Steel
Mounting
Wall
Enclosure Color
Silver
Lamp Module Voltage
Module Not Included
Voltage
300 V
Terminal Connection
direct connection AWG 2) solid stranded || direct connection AWG 12) solid stranded || direct connection AWG 24) solid stranded
Operator Color
Black
IP Rating
IP66
Number of Speeds
1
Application
for hoisting and mechanical handling applications
Contact Block Name
KA1
Control Station Composition
1 selector switch 1 NO/1 NC
Connections - Terminals
Direct connection AWG 2) solid stranded; Direct connection AWG 12) solid stranded; Direct connection AWG 24) solid stranded
Mechanical Interlocking
Without mechanical interlock
Connector Type
Screw clamp connector
Ambient Air Temperature For Operation
-13 to 140°F (-25 to 60°C)
Enclosure/Cubicle Description
Wall-mounted enclosure 1 cut-out 30 mm
NEMA Degree Of Protection
NEMA 13; NEMA 3; NEMA 1; NEMA 4
Provided Equipment
Label plate HAND-OFF-AUTO
Rated Operational Current AC
10 A
Ambient Air Temperature For Storage
-40 to 158°F (-40 to 70°C)
Level Or Class
Class II Division 2 Group G; Class III
Environmental Characteristic
Resistant against immersion in water; Dust and oil resistant
Operating Temperature - Maximum
140 Degrees F
NEMA Enclosure Rating
1, 13, 3, 4
Includes Mechanical Interlock
No Mechanical Interlock Included.
Selector Switch Number of Positions
3
DC Contact Rating
0.2 A @ 600 V, 0.55 A @ 240 V, 1.1 A @ 120 V
Operating Temperature - Minimum
-13 Degrees F
Hazardous Location Specification
Class II, Div 2, Group G, Class III, Div 1 and 2
AC Contact Rating
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Product Type
Control Station
Operator Configuration
Selector Switch

Description

Control Station, Number of Operators 1, Number of Pilot Lights 0, Size 30 mm, Legend Hand/Off/Auto, Type of Operator Selector Switch, Action Maintained/Maintained/Maintained, Operator Color Black, Contact Form 1NO/1NC, Mechanical Interlock No, NEMA Rating 1, 13, 3, 4, Contact Rating 10A @ 300V, IP Rating IP66, Mounting Wall, Enclosure Material Stainless Steel, Enclosure Color Silver, Standards UL Listed, Lamp Module Voltage Module Not Included
