  15. ControlStation, Dead-End, 2Buttons, Blk
Schneider Electric ControlStation, Dead-End, 2Buttons, Blk 9001BW256 - main

ControlStation, Dead-End, 2Buttons, Blk

  • Mfr # 9001BW256

  • Zoro # G0198864

product price: $293.99
/ea
Free Shipping & Returns

Key Features

Number of Gangs
1
Legend
On/Off
Number of Pilot Lights
0
Type of Operator
Flush Button
Contact Form
1NO/1NC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
9001BW256
Zoro #
G0198864
UPC #
785901857747
Country of Origin
Mexico

Dimensions

Width
2.76 in
Height
4.25 in
Depth
3.58 in
Overall Height
4.25 in
Overall Width
2.76 in
Overall Depth
3.6 in
Hub Size - Maximum
1/2 in
Manufacturer Warranty Length
18 mo
Cad Overall Width
70 mm
Cad Overall Depth
91 mm
Cad Overall Height
108 mm

Details

Item
Control Station
Number of Gangs
1
Legend
On/Off
Number of Pilot Lights
0
Type of Operator
Flush Button
Contact Form
1NO/1NC
Number of Operators
2
NEMA Rating
1, 4
Hub Style
Dead-End
Series
9001
Contact Rating
0.6 A @ 600 V AC, 0.6A @ V DC, 0.75 A @ 480 V AC, 1.5 A @ 240 V AC, 3.75 A @ 120 V AC
Standards
CSA, UL Listed
Action
Maintained/Maintained
Hub
1/2 in NPT
Mechanical Interlock
Yes
Lamp Module Voltage
Module Not Included
DC Contact Rating
0.2 A @ 600 V, 0.55 A @ 240 V, 1.1 A @ 120 V
Enclosure Material
Zinc
Material
cast aluminium
Enclosure Color
Gray
Mounting
Wall
Operator Color
(2) Black
AC Contact Rating
0.6 A @ 600 V, 0.75 A @ 480 V, 1.5 A @ 240 V, 3.75 A @ 120 V
NEMA Enclosure Rating
1, 13, 4
Operating Temperature - Minimum
-13 Degrees F
Number of Speeds
1
Includes Mechanical Interlock
Mechanical Interlock Included
Hazardous Location Specification
Not Rated
Operating Temperature - Maximum
158 Degrees F
Operator Configuration
(2) Flush Push Buttons
Mounting Style
Surface
Product Type
Control Station
Device Mounting
surface
Mechanical Durability
5000000 cycles
Ambient Air Temperature For Storage
-40-70°C
Product Certifications
UL Listed || CSA
Control Station Composition
1 flush push-button, black, white ON || 1 flush push-button, black, white OFF
Nema Degree Of Protection
NEMA 1 || NEMA 4
Type Of Installation
indoor/outdoor
Control Station Application
two functions
Cable Entry
1 entry for 1/2" - 14 NPT
Contact Operation
interlocked
Contacts Type And Composition
1 NO + 1 NC
Ambient Air Temperature For Operation
-25-70°C
Device Short Name
9001BW
[Ie] Rated Operational Current
0.6 A 600 V, AC-1/DC-1 || 0.75 A 480 V, AC || 1.5 A 240 V, AC || 3.75 A 120 V, AC
Environmental Characteristic
waterproof || dustproof
Product Or Component Type
complete control station
Colour Of Base Of Enclosure
grey
Rated Operational Current
0.6 A 600 V, AC-1/DC-1; 0.75 A 480 V, AC; 1.5 A 240 V, AC; 3.75 A 120 V, AC

Description

Control Station, Number of Operators 2, Number of Pilot Lights 0, Legend On/Off, Type of Operator Flush Button, Action Maintained/Maintained, Operator Color (2) Black, Contact Form 1NO/1NC, Mechanical Interlock Yes, NEMA Rating 1, 4, Contact Rating 0.6 A @ 600 V AC, 0.6A @ V DC, 0.75 A @ 480 V AC, 1.5 A @ 240 V AC, 3.75 A @ 120 V AC, IP Rating Not Applicable, Mounting Wall, Hub 1/2 in NPT, Height 4.25 in, Width 2.76 in, Depth 3.58 in, Enclosure Material Zinc, Enclosure Color Gray
