Schneider Electric DIN Rail & Top Flange, Enclosed Power Relay, Square, 30 A, 6, 1/4 in Tab Terminal 92S7A22D-120A

DIN Rail & Top Flange, Enclosed Power Relay, Square, 30 A, 6, 1/4 in Tab Terminal (Discontinued)

  • Mfr # 92S7A22D-120A
  • Zoro # G2290127
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
92S7A22D-120A
Zoro #
G2290127
UPC #
-
Country of Origin
China

Dimensions

Dimensions
1.49"H, 1.36"W, 2.70"D
Overall Height - Relay
1.49 in
Flat Pin Width
0.25 in
Overall Depth
1.54 in
Body Height
1.54 in
Body Width
1.33 in
Body Depth
2.7 in
Body Width - Relay
1.36 in
Body Depth - Relay
2.7 in
Body Height - Relay
1.49 in

Details

Item
Enclosed Power Relay
Mounting Style
DIN Rail & Top Flange
Electrical Connection
1/4 in Tab Terminal
Base Shape
Square
Number of Pins
6
Coil Voltage
120V AC
Current Rating
30 A
Contact Form
DPST-NO
Contact Rating (AC)
10 A @ 120V, 3 A @ 250/277V, 30 A @ 250/277V, 6 A @ 250V, 96 A @ 240V
Contact Rating (DC)
20 A @ 28V, 25 A @ 28V, 3 A @ 28V
Coil Rating
4.0VA, 1.7W
Coil Volts
120V AC
Electrical Connection - Power Relay
1/4 in Tab Terminal
Mounting - Relay
Bottom Flange, DIN Rail
Pins
6
Contact Material
Silver Alloy
Standards
CE Certified, CSA Certified, UL Listed
Contact Amp Rating (Resistive)
30A @ 277VAC, 20A @ 28VDC
HP @ 120V
1
Power Consumption - Relay
4.0 VA
Features
Class F Coil Insulation, Sealed Construction
Contact Form - Relay
DPST-NO
HP @ 240V
3
DC Contact Rating - Relay
20A @ 28V
Number of Pins - Relay
6
Number of Poles
2
AC Contact Rating - Relay
30A @ 277V
Mounting
Flange, Bottom/Din Rail
Hz
50/60
Item - Relay
Enclosed Power Relay
Hz - Electrical
50/60 Hz
Dielectric Strength
1,500V AC Between Contacts, 2,000V AC Between Poles, 4,000V AC Between Coil and Contact
Response Time
25 msec
Horsepower @ 240V AC
3 hp
Input Voltage
120V AC
Coil Resistance
4,250 ohm
Sealing
Sealed
Series
92 Power Series
Mechanical Operating Durability
5,000,000
Minimum Operating Temperature
-40 Degrees F
Base Type
DIN, Flange
Maximum Operating Temperature
131 Degrees F
Power Consumption
4.4 VA
Operating Current
30 A
Electrical Operating Durability
100,000
Frequency
50/60 Hz
Horsepower @ 120V AC
1 hp
Maximum Switching Voltage
250V DC, 300V AC
Weight
2.89 oz
Motor Rated
Yes
CAD Available
Yes
Status Indicator
No Indicator
Type
Power

Description

Enclosed Power Relay, Base Shape Square, Coil Voltage 120V AC, Contact Form DPST-NO, Current Rating 30 A, Electrical Connection 1/4 in Tab Terminal, Flat Pin Width 0.25 in, Number of Pins 6, Sealing Sealed, Status Indicator No Indicator, Contact Rating (AC) 10 A @ 120V, 3 A @ 250/277V, 30 A @ 250/277V, 6 A @ 250V, 96 A @ 240V, Contact Rating (DC) 20 A @ 28V, 25 A @ 28V, 3 A @ 28V, Horsepower @ 120V AC 1 hp, Horsepower @ 240V AC 3 hp, Mounting Style DIN Rail & Top Flange, Body Depth 1.18 in
