Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Non-Reversing, Screw Clamp LC1D65ABBE - main

IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Non-Reversing, Screw Clamp

  • Mfr # LC1D65ABBE

  • Zoro # G6567080

product price:  $353.99
/ea
Item requires special delivery charges. A $85.00 per item surcharge will be applied.

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
24V DC
Number of Poles
3
Full Load Amps-Inductive
65 A
Full Load Amps-Resistive
80 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LC1D65ABBE
Zoro #
G6567080
UPC #
785901765318
Country of Origin
France

Dimensions

Working Height
Up to 9842.52 ft
Overall Depth
4.72 in
Overall Height
4.8 in
Overall Width
2.17 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC/1NO
Coil Voltage
24V DC
Number of Poles
3
Full Load Amps-Inductive
65 A
Full Load Amps-Resistive
80 A
Reversing Capability
Non-Reversing
Terminal Connection Type
Screw Clamp
Number of Auxillary Contacts
2
Standards
CCC, CSA, CSA C22.2 No 60947-4-1, DNV-GL, EAC, EN/IEC 60947-4-1, EN/IEC 60947-5-1, IEC 60335-1, KC, LROS, UKCA, UL Listed, UL 60947-4-1
Enclosure NEMA Rating
No Enclosure
Reversing
No
HP @ 3 Phase - 575V
50 hp
Frame / Series / Class / Code
TeSys
Includes
Everlink Power Connections
Series
TeSys Deca Green
Mechanical Durability
6 Mcycles
Net Weight
1.002 kg
Environmental Attributes
Mercury Free, Pollution Degree 3
Control Circuit Voltage Limits
Drop-Out DC: Less Than 0.1 Uc (at -40 to 70°C); Operational DC: 0.8 to 1.2 Uc (at -40 to 60°C), 1 to 1.2 Uc (at 60 to 70°C)
Includes Protective Cover
Yes
Rated Making Capacity
1000 A @ 440V (Power Circuit), 140 A (AC Signalling Circuit), 250 A (DC Signalling Circuit)
Electrical Durability
1.8 Mcycles (57 A, AC-3, Less than 440 V); 0.5 Mcycles (80 A, AC-1, Less than 440 V); 1.8 Mcycles (57 A, AC-3e, Less than 440 V)
Max. Operating Watts
18.5 kW (at 220 to 230V AC 50 Hz AC-3), 30 kW (at 380 to 400V AC 50 Hz AC-3), 37 kW (at 415V AC 50 Hz AC-3), 37 kW (at 440V AC 50 Hz AC-3), 37 kW (at 500V AC 50 Hz AC-3), 37 kW (at 660 to 690V AC 50 Hz AC-3), 18.5 kW (at 220 to 230V AC 50 Hz AC-3e), 30 kW (at 380 to 400V AC 50 Hz AC-3e), 37 kW (at 415V AC 50 Hz AC-3e), 37 kW (at 440V AC 50 Hz AC-3e), 37 kW (at 500V AC 50 Hz AC-3e), 37 kW (at 660 to 690V AC 50 Hz AC-3e)
Operating Speed
3600 cycles per hr
Fuse Amps
125 A (Type 1 and 2 Power Circuit), 10 A (Signalling Circuit)
IP Rating
IP20
Impedance
1.5 mOhm
Tightening Torque
1.7 Nm (Control Circuit), 5 to 8 Nm (Power Circuit)
Insulation Resistance Range
Greater Than 10 MOhms (Signalling Circuit)
Operating Time
55 to 65 ms (Closing), 20 to 120 ms (Opening)
Rated Insulation Volts
690V
Vibration Resistance
4 G (Contactor Closed), 2 G (Contactor Open)
Switching Current
5 mA (Signalling Circuit)
Rated Breaking Capacity
1000 A @ 440V
Application
Motor Control, Resistive Load
Watts Loss
0.5W
Impulse Withstand Voltage
6 kV
Non-Overlap Time
1.5 ms
Overvoltage Category
CAT III
Shock Resistance
15 G for 11 ms (Contactor Closed), 10 G for 11 ms (Contactor Open)
Signalling Circuit Frequency
25 to 400 Hz
Fire Rating
UL 94 V1
Rated Short-Time Withstand Current
110 A (at 40°C for 10 min Power Circuit), 260 A (at 40°C for 1 min Power Circuit), 520 A (at 40°C for 10 s Power Circuit), 900 A (at 40°C for 1 s Power Circuit), 100 A (For 1 s Signalling Circuit), 120 A (For 500 ms Signalling Circuit), 140 A (For 100 ms Signalling Circuit)
Switching Voltage
17 V (Signalling Circuit)
Features
Built-In Bi-Directional Peak Limiting
Minimum Operating Temperature
-40 Degrees F
Horsepower @ Three Phase - 208V AC
20 hp
Horsepower @ Single Phase - 120V AC
5 hp
Frequency
50 Hz
Full Load Current - Inductive
65 A
NEMA Enclosure Rating
No Enclosure
Mounting Style
DIN Rail, Plate
Includes Auxiliary Contacts
Yes
Phase
Three
Horsepower @ Three Phase - 240V AC
20 hp
Embedded Surge Suppressor
No
Resistance Properties
Fire Resistant, Insulation Resistant
Full Load Current - Resistive
80 A
Electrical Operating Durability
1,800,000, 500,000
Horsepower @ Three Phase - 480V AC
40 hp
Horsepower @ Three Phase - 600V AC
50 hp
Horsepower @ Single Phase - 240V AC
10 hp
Mechanical Operating Durability
6,000,000
Maximum Operating Temperature
140 Degrees F
Contactor Style
IEC
Number of Normally Open Main Contacts
3
Maximum Voltage Rating
690V AC
Conventional Free Air Thermal Current
80 A (at 60°C Power Circuit), 10 A (at 60°C Signalling Circuit)

Description

The IEC Magnetic Contactor is an electrically operated switching device rated for operation within specified motor control and resistive-load applications. It is a 3-pole, non-reversing unit with a 24 V DC coil and a 1 normally open/1 normally closed auxiliary contact configuration. Compatible with screw clamp terminals for control circuits and EverLink power connections within specified parameters, and it conforms to IEC standards; designed according to TeSys Deca Green series specifications.

Coil voltage: 24 V DC

  • Poles / Auxiliary contacts: 3 poles; 2 auxiliary contacts (1NO/1NC)
  • Reversing: Non-Reversing
  • Contactor style / series: IEC; TeSys Deca Green
  • Rated voltage / frequency: rated for operation at voltages up to 690 V AC, 50/60 Hz frequency range
  • Full load amps: rated for full load currents of up to 80 A resistive, 65 A inductive within specified conditions
  • Rated making capacity: rated making capacity based on specified test conditions; actual performance may vary depending on application conditions
  • Short-time withstand current: capable of withstanding short-term current surges as specified; actual performance depends on operating environment
  • Durability (mechanical / electrical): mechanical/electrical durability ratings under standard testing conditions; real-world lifespan may vary based on usage patterns
  • Electrical connections: Control Circuit—Screw Clamp; Power Circuit—EverLink BTR Screw Connectors
  • Includes / protection: Everlink Power Connections; Includes Auxiliary Contacts; Includes Protective Cover
  • Environmental / rating: complies with IP20 environmental rating, pollution degree classification, and fire safety standards per UL94 V1
  • Standards: CCC, CSA, CSA C22.2 No 60947-4-1, DNV-GL, EAC, EN/IEC 60947-4-1, EN/IEC 60947-5-1, IEC 60335-1, KC, LROS, UKCA, UL Listed, UL 60947-4-1
  • Dimensions / weight: Net weight 1.002 kg; Height 4.8 in; Width 2.17 in; Depth 4.72 in
  • Operating characteristics: Non-overlap time 1.5 ms; Operating times: 55–65 ms (Closing), 20–120 ms (Opening)
  • Environmental / operating: Impulse withstand voltage 6 kV; Signalling circuit frequency 25–400 Hz; 5 mA switching current; 17 V signalling voltage
  • Mounting / installation: DIN Rail, Plate mounting; Mounts on Plate, Rail
  • Working height: Up to 9842.52 ft
  • Phase: Three
  • Max / operating temperature: Max. temp 850°C; Max operating temperature 140°F
