  15. Illuminated Push Button, 30 mm, SPDT, Amber
Schneider Electric Illuminated Push Button, 30 mm, SPDT, Amber 9001K2L1AH13 - main

Illuminated Push Button, 30 mm, SPDT, Amber

  • Mfr # 9001K2L1AH13

  • Zoro # G0402972

product price: $212.99
/ea
Free Shipping & Returns

Key Features

Push Button Style
Extended
Action
Momentary
Operator Illumination
Illuminated
Panel Cutout Diameter
30 mm
Head Color
Amber
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001K2L1AH13
Zoro #
G0402972
UPC #
785901027522
Country of Origin
Mexico

Dimensions

Panel Cutout Diameter
30 mm
Size
30 mm
Mounting Diameter
30 mm
Manufacturer Warranty Length
18 mo

Details

Item
Illuminated Push Button
Push Button Style
Extended
Action
Momentary
Operator Illumination
Illuminated
Head Color
Amber
Head Material
Metal
Terminal Connection
Screw Clamp
Standards
CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, WEEE
Lamp Type
Incandescent
NEMA Contact Rating Designation
A600/Q600
Bezel
Chrome Plated Zinc Die Cast
Lamp Module Voltage
120V AC
Lamp Voltage
6V AC
NEMA Rating
1, 12, 13, 2, 3, 3R, 4, 6
Type of Operator
Round Guarded Button
Lamp Module Type
Transformer
Contact Form
SPDT
Contact Type
1NO/1NC
Voltage
120V AC
Replacement Lamp
Mfr. No. 755
Contact Rating
10A @ 600V AC
Color
Amber
Number of Operators
1
IP Rating
IP66
Basic Material
Metal
Series
9001K
Bezel Material
Metal
DC Contact Rating
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
AC Contact Rating
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Product Type
Push Button Operators
[Ie] Rated Operational Current
10 A, AC-15 || 10 A, DC-13
Supply Frequency
50 to 60 Hz
Device Short Name
K
Operating Position
any position
[Us] Rated Supply Voltage
110 to 120 V, 110 to 120 V AC
Device Presentation
complete product
Bulb Base
BA 9s
Operator Additional Information
without guard
Cap/Operator Or Lens Colour
amber
Nema Degree Of Protection
NEMA 1/2/3/3R/4/6/12/13
Contacts Type And Composition
1 C/O
Product Certifications
NEMA || UL listed file E42259 CCN NKCR || CSA LR 25490 class 3211 03 || CE
Operator Profile
amber projecting, projecting
Product Or Component Type
illuminated push-button
Light Block Supply
via integral transformer
Contact Operation
standard
Connections - Terminals
screw clamp terminals
Light Source
incandescent, incandescent bulb
Rated Supply Voltage
110 to 120 V AC
Rated Operational Current
10 A, AC-15; 10 A, DC-13
Operator Voltage Rating - Maximum
600 V AC
Operator Material
Metal
Operating Temperature - Minimum
-22 Degrees F
Lamp Voltage - Maximum
120 V AC
Number of Indicator Lights
0
Hazardous Location Specification
Class I, Div 2, Group A, B, C, D, Class II, Div 2, Group E, F, G, Class III, Div 1 and 2
Resistance Properties
Corrosion Resistant, Dust Resistant, Impact Resistant, Vibration Resistant, Watertight
Operating Temperature - Maximum
140 Degrees F
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4, 6

Description

Illuminated Push Button, 30 mm, Momentary Action, Round Guarded Button Type of Operator, Head Material Metal, Contact Form SPDT, Bezel Chrome Plated Zinc Die Cast, Color Amber, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, Number of Operators 1, NEMA Rating 1, 12, 13, 2, 3, 3R, 4, 6, IP Rating IP66, Legend Not Applicable, Standards CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, WEEE, Terminal Connection Screw Clamp
