  15. Illuminated Push Button Operator, 16 mm, Green
Schneider Electric Illuminated Push Button Operator, 16 mm, Green ZB6AW3 - main

Illuminated Push Button Operator, 16 mm, Green

  • Mfr # ZB6AW3

  • Zoro # G2951663

product price: $11.95
/ea

Key Features

Push Button Style
Flush
Action
Momentary
Operator Illumination
Illuminated
Panel Cutout Diameter
16 mm
Head Color
Green
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZB6AW3
Zoro #
G2951663
UPC #
785901360506
Country of Origin
Spain

Dimensions

Panel Cutout Diameter
16 mm
Size
16 mm
Mounting Diameter
16 mm
Cad Overall Height
18 mm
Cad Overall Depth
33 mm
Cad Overall Width
18 mm
Overall Height
0.71 in
Overall Depth
1.3 in
Manufacturer Warranty Length
18 mo
Overall Width
0.71 in

Details

Item
Push Button Operator
Push Button Style
Flush
Action
Momentary
Operator Illumination
Illuminated
Head Color
Green
Head Material
Plastic
Standards
CCC, CSA C22.2 No.14, CSA C22.2 No.94, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-5, GOST, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, JIS C852, JIS C8201-1, JIS C8201-5-1, REACH Free of SVHC, RoHS, UL Listed, UL 508
Lamp Module Voltage
Module Not Included
Lamp Type
No Lamp Module Included
Color
Green
NEMA Rating
13, 4, 4X
Basic Material
Plastic
Lamp Voltage
Dependent on Module Used
Replacement Lamp
Mfr. No. ZB6EB1B through ZB6EH0B
Lamp Module Type
No Lamp Module Included
Type of Operator
Flush Button
Bezel
Plastic
IP Rating
IP65
Bezel Material
Plastic
Number of Operators
1
Series
XB6
Features
Spring Return Mechanism
Shape Of Signaling Unit Head
round
Ip Degree Of Protection
IP65 IEC 60529
Device Short Name
ZB6
Product Certifications
GOST || UL || CCC || CSA
Operator Profile
green flush, unmarked
Nema Degree Of Protection
NEMA 13 UL 50 || NEMA 4 UL 50 || NEMA 4X UL 50 || NEMA 4 CSA C22.2 No 94 || NEMA 4X CSA C22.2 No 94 || NEMA 13 CSA C22.2 No 94
Electrical Shock Protection Class
class II IEC 61140
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Protective Treatment
TC
Product Or Component Type
head for illuminated push-button
Product Compatibility
integral LED
Ambient Air Temperature For Storage
-40-70°C
Ambient Air Temperature For Operation
-25-70°C
Vibration Resistance
+/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Operator Material
Plastic
Hazardous Location Specification
Not Rated
Product Type
Push Button Operators
Resistance Properties
Shock Resistant, Vibration Resistant
NEMA Enclosure Rating
1, 12
Number of Indicator Lights
1
Operating Temperature - Minimum
-13 Degrees F
Operating Temperature - Maximum
158 Degrees F

Description

Flush Push Button, 16 mm, Momentary, Type of Operator Flush Button, Basic Material Plastic, Head Material Plastic, Bezel Material Plastic, Color Green, NEMA Rating 13, 4, 4X, IP Rating IP65, Legend Not Applicable, Standards CCC, CSA C22.2 No.14, CSA C22.2 No.94, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-5, GOST, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, JIS C852, JIS C8201-1, JIS C8201-5-1, REACH Free of SVHC, RoHS, UL Listed, UL 508, Features Spring Return Mechanism
