  15. Illuminated Push Button Operator, 16 mm, Red
Schneider Electric Illuminated Push Button Operator, 16 mm, Red ZB6DW4 - main

Illuminated Push Button Operator, 16 mm, Red

  • Mfr # ZB6DW4

  • Zoro # G2216051

product price: $11.95
/ea

Key Features

Push Button Style
Flush
Action
Momentary
Operator Illumination
Illuminated
Panel Cutout Diameter
16 mm
Head Color
Red
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZB6DW4
Zoro #
G2216051
UPC #
785901363460
Country of Origin
Spain

Dimensions

Panel Cutout Diameter
16 mm
Size
16 mm
Cad Overall Width
24 mm
Mounting Diameter
16 mm
Cad Overall Depth
33 mm
Cad Overall Height
18 mm
Overall Depth
1.3 in
Overall Width
0.94 in
Overall Height
0.71 in
Manufacturer Warranty Length
18 mo

Details

Item
Push Button Operator
Push Button Style
Flush
Action
Momentary
Operator Illumination
Illuminated
Head Color
Red
Head Material
Plastic
Standards
CCC, CSA C22.2 No.14, CSA C22.2 No.94, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-5, GOST, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, JIS C852, JIS C8201-1, JIS C8201-5-1, REACH Free of SVHC, RoHS, UL Listed, UL 508
Lamp Voltage
Dependent on Module Used
Replacement Lamp
Mfr. No. ZB6EB1B through ZB6EH0B
Basic Material
Plastic
Bezel
Plastic
Color
Red
Type of Operator
Rectangular Flush Button
Lamp Module Type
No Lamp Module Included
Lamp Type
No Lamp Module Included
IP Rating
IP65
NEMA Rating
13, 4, 4X
Lamp Module Voltage
Module Not Included
Bezel Material
Plastic
Series
XB6
Number of Operators
1
Features
Spring Return Mechanism
Ambient Air Temperature For Storage
-40-70°C
Electrical Shock Protection Class
class II IEC 61140
Product Compatibility
integral LED
Vibration Resistance
+/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Shape Of Signaling Unit Head
rectangular
Operator Profile
red flush, unmarked
Protective Treatment
TC
Ip Degree Of Protection
IP65 IEC 60529
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Device Short Name
ZB6
Product Certifications
CCC || GOST || CSA || UL
Product Or Component Type
head for illuminated push-button
Nema Degree Of Protection
NEMA 13 UL 50 || NEMA 4 UL 50 || NEMA 4X UL 50 || NEMA 4 CSA C22.2 No 94 || NEMA 4X CSA C22.2 No 94 || NEMA 13 CSA C22.2 No 94
Ambient Air Temperature For Operation
-25-70°C
Resistance Properties
Shock Resistant, Vibration Resistant
Operating Temperature - Maximum
158 Degrees F
NEMA Enclosure Rating
1, 12
Number of Indicator Lights
1
Operator Material
Plastic
Hazardous Location Specification
Not Rated
Product Type
Push Button Operators
Operating Temperature - Minimum
-13 Degrees F

Description

Flush Push Button, 16 mm, Momentary, Type of Operator Rectangular Flush Button, Basic Material Plastic, Head Material Plastic, Bezel Material Plastic, Color Red, NEMA Rating 13, 4, 4X, IP Rating IP65, Legend Not Applicable, Standards CCC, CSA C22.2 No.14, CSA C22.2 No.94, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-5, GOST, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, JIS C852, JIS C8201-1, JIS C8201-5-1, REACH Free of SVHC, RoHS, UL Listed, UL 508, Features Spring Return Mechanism
