  11. Jumper, 2 Pole, 0.88 in L
Schneider Electric Jumper, 2 Pole, 0.88 in L NSYTRAL22 - main

Jumper, 2 Pole, 0.88 in L

  • Mfr # NSYTRAL22

  • Zoro # G5234607

product price: $1.29
/ea

Key Features

For Use With
Mfr. No. NSYTRV24D, NSYTRV22, NSYTRV22PE
Number of Poles
2
Length
0.88 in
Material
Polyamide 6.6, Copper Alloy
Width
0.07"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
NSYTRAL22
Zoro #
G5234607
UPC #
785901445623
Country of Origin
Germany

Dimensions

Length
0.88 in
Width
0.07"
Height
0.38"
Length (Straight Wireway)
0.88 in
Overall Depth
0.79 in
Overall Length
0.88 in
Overall Width
1.57 in

Details

Item
Terminal Block Jumper
For Use With
Mfr. No. NSYTRV24D, NSYTRV22, NSYTRV22PE
Number of Poles
2
Material
Polyamide 6.6, Copper Alloy
Color
Red
RoHS Compliant
Yes
Compatible with Product Type
TRH IDC, TRP Push-in, TRR Spring- Blade Disconnect, TRR Spring- Passthrough, TRR Spring - Protective Earth, TRR Spring - Removable Carrier Disconnect, TRV Screw
Connection Orientation
It Provides 2 Ways for 2.5mm² Terminals
Compatible with Series
TRH IDC, TRP Push-in, TRR Spring- Blade Disconnect, TRR Spring- Passthrough, TRR Spring - Protective Earth, TRR Spring - Removable Carrier Disconnect, TRV Screw
Special Features
Mercury Free, Toxic Heavy Metal Free, Warranty 18 Months
Number of Ways
2
Insulation Material
Plastic
Compatible Manufacturer Model Number
NSYTRV24D, NSYTRV22, NSYTRV22PE
Contact Material
Copper
Number Of Measurement Input
2 || 6 || 1 || 3 || 4
Product Name
Linergy TR
Product Or Component Type
plug-in bridge
Cable Cross Section
2.5-2.5 mm²
Number Of Terminals
3 || 4 || 2
Product Compatibility
TRV screw terminal terminal block || TRP push-in terminal block || TRH IDC terminal block || TRR spring terminal - passthrough terminal block || TRR spring terminal - protective earth terminal block, length = 78 mm || TRR spring terminal - blade disconnect terminal block || TRR spring terminal - removable carrier disconnect terminal block
Range
Linergy
Device Short Name
TRA
Accessory / Separate Part Category
connection accessory

Description

Terminal Block Jumper, Compatible with Series TRH IDC, TRP Push-in, TRR Spring- Blade Disconnect, TRR Spring- Passthrough, TRR Spring - Protective Earth, TRR Spring - Removable Carrier Disconnect, TRV Screw, Connection Orientation Vertical, Contact Material Copper, Current Not Applicable, Insulation Material Plastic, Number of Poles 2, Overall Depth 0.79 in, Overall Length 0.88 in, Overall Width 1.57 in, Color Red, Compatible Manufacturer Model Number NSYTRV24D, NSYTRV22, NSYTRV22PE
