Shop SCHNEIDER ELECTRIC

Non-Illum Push Button Operator, Black

  • Mfr # ZB5AD28

  • Zoro # G0938831

product price:
$
43.25
/ea

Key Features

Number of Connections
1
Action
Maintained
Size
22 mm
Head Material
Plastic
Standards
CE, CSA, RoHS, UL Listed
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ZB5AD28
Zoro #
G0938831
UPC #
785901385707
Country of Origin
Korea, Republic of

Dimensions

Size
22 mm
Cad Overall Depth
45 mm
Cad Overall Width
29 mm
Mounting Diameter
22 mm
Cad Overall Height
29 mm
Overall Depth
1.77 in
Overall Width
1.14 in
Mounting Hole Diameter
0.87 in
Manufacturer Warranty Length
18 mo
Overall Height
1.14 in

Details

Number of Connections
1
Action
Maintained
Head Material
Plastic
Standards
CE, CSA, RoHS, UL Listed
Item
Toggle Switch
Color
Black
NEMA Rating
1, 13, 2, 3, 4, 4X
IP Rating
IP69
Accessory Group
A
Type of Operator
2-Position Toggle Switch
Bezel Material
Double-Insulated Plastic
Basic Material
Plastic
Legend
No Legend
Number of Operators
1
Series
ZB5
Product Type
Toggle Switch
Electrical Composition Code
C11 3 single front mounting || C12 6 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || SR1 3 single rear mounting || C13 6 single and double front mounting
Product Certifications
DNV || GL || UL Listed || BV || CSA || LROS (Lloyds register of shipping)
Product Or Component Type
head for selector switch
Mechanical Durability
500000 cycles
Device Short Name
ZB5
Ip Degree Of Protection
IP66 IEC 60529
Head Type
standard
Operator Profile
black toggle switch
Vibration Resistance
5 gn 2-500 Hz)IEC 60068-2-6
Protective Treatment
TH
Ik Degree Of Protection
IK06
Station Name
XALD 1 to 5 cut-outs || XALK 2 to 5 cut-outs
Resistance To High Pressure Washer
7000000 Pa 55°C 0.1 m
Overvoltage Category
class II IEC 60536
Operator Additional Information
black lever
Device Presentation
basic element
Ambient Air Temperature For Storage
-40-70°C
Nema Degree Of Protection
NEMA 13 || NEMA 4X
Ambient Air Temperature For Operation
-40-70°C
Shape Of Signaling Unit Head
round
Operator Position Information
2 positions 90°
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Number of Positions
2
Switch Function Configuration
On/Off
Resistance Properties
Vibration Resistant
Operator Illumination Style
Non-Illuminated
Actuator Material
Plastic
Terminal Connection Type
Spring Terminals
Operating Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
158 Degrees F
NEMA Enclosure Rating
13, 4X

Description

Toggle Switch, Contact Form Not Applicable, Number of Connections 1, AC Contact Rating Not Applicable, DC Contact Rating Not Applicable, Standards CE, CSA, RoHS, UL Listed, Includes Not Applicable
