Schneider Electric Non-Illum Selectr Swtch, 22mm, 2 Pos, Keyd 9001KS11BH13 - main

Non-Illum Selectr Swtch, 22mm, 2 Pos, Keyd

  • Mfr # 9001KS11BH13

  • Zoro # G2081073

product price: $106.99
/ea
Free Shipping & Returns

Key Features

Size
30 mm
Basic Material
Metal
Type of Operator
Lever
Contact Form
1NC, 1NO
Action
Maintained/Maintained
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001KS11BH13
Zoro #
G2081073
UPC #
785901330226
Country of Origin
Mexico

Dimensions

Size
30 mm
Mounting Diameter
30 mm
Panel Cutout Diameter
30 mm
Manufacturer Warranty Length
18 mo

Details

Item
Selector Switch
Basic Material
Metal
Type of Operator
Lever
Contact Form
1NC, 1NO
Action
Maintained/Maintained
Cam
E
Operator Head Material
Polycarbonate
Color
Black
NEMA Rating
12, 13, 3, 3R, 4
Bezel Material
Metal
Position
2
Key Removal
No Key
Bezel Color
Black
Switch Operation @ Position B
XO
Switch Operation @ Position D
No Fourth Position
Standards
CE, CSA LR24590 Class 3211 03, UL E42259 CCN NKCR
Switch Operation @ Position C
No Third Position
IP Rating
IP66
Switch Operation @ Position A
OX
Contact Rating
10A @ 600V AC
NEMA Contact Rating Designation
A600/Q600
Series
9001K
DC Contact Rating
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @125 V
AC Contact Rating
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Cap/Operator Or Lens Colour
black
Product Or Component Type
selector switch
Device Presentation
complete product
Connections - Terminals
screw-clamp terminals, 1 x 0.22 to 2 x 1.5 mm² IEC 60947-1
Operator Profile
black standard knob, standard handle
Nema Degree Of Protection
NEMA 1/2/3/3R/4/6/12/13
Product Compatibility
9001KA1 side 2
Contacts Type And Composition
1 C/O
Operator Position Information
2 positions
Product Certifications
CE || CSA LR24590 class 3211 03 || UL listed file E42259 CCN NKCR
Device Short Name
K
Cam Profile
5
Contact Block Material
Metal
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4
Operator Illumination
Non-Illuminated
Switch Function @ 3rd Position
No Third Position
Operator Head Type
Short-Handled Knob
Switch Function @ 1st Position
Off
Switch Function @ 2nd Position
On
Number of Positions
2
Switch Function @ 4th Position
No Fourth Position
Operator Head Color
Black
Hazardous Location Specification
Not Rated

Description

Selector Switch, 30 mm, 2 Position, Maintained/Maintained Action, 1NC, 1NO Contact Form, Type of Operator Lever, Color Black, No Key Key Removal, Operator Head Material Polycarbonate, Basic Material Metal, Bezel Material Metal, Bezel Color Black, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, NEMA Rating 12, 13, 3, 3R, 4, IP Rating IP66, Cam E, Switch Operation @ Position A OX, Switch Operation @ Position B XO, Switch Operation @ Position C No Third Position
