  11. Open Power Relay, Surface Mounted, SPST-NC, 480V AC, 4 Pins, Poles
This item is Discontinued.
Schneider Electric Open Power Relay, Surface Mounted, SPST-NC, 480V AC, 4 Pins, Poles 8501CO8V29

Open Power Relay, Surface Mounted, SPST-NC, 480V AC, 4 Pins, Poles (Discontinued)

  • Mfr # 8501CO8V29
  • Zoro # G3464082
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8501CO8V29
Zoro #
G3464082
UPC #
785901089766
Country of Origin
China

Dimensions

Body Height - Relay
2.43 in
Overall Height - Relay
2.43 in
Body Width - Relay
2.5 in
Body Depth - Relay
2.25 in
Overall Depth
1.98 in
Body Height
2.49 in
Body Depth
1.07 in
Body Width
2.5 in

Details

Item - Relay
Power Relay
Coil Volts
480V AC
AC Contact Rating - Relay
30A @ 300V
Contact Form - Relay
SPST-NC
Mounting - Relay
Through Panel
Power Consumption - Relay
10.0 VA
Contact Material
Copper
Electrical Connection - Power Relay
Screw Clamp
HP @ 240V
2
Electrical Connection
Screw Clamp
Hz - Electrical
50/60 Hz
Contact Form
SPST-NC
Item
Open Power Relay
Standards
CE Certified, CSA Certified, UL File No. E78351 CCN NLDX
HP @ 120V
2
Features
Durable Open-Frame Construction, Green Premium Product
Horsepower @ 240V AC
2 hp
Mounting Style
Through Panel
Motor Rated
Yes
Number of Pins
4
Contact Rating (AC)
30 A @ 300V
Minimum Operating Temperature
-22 Degrees F
Maximum Operating Temperature
122 Degrees F
Sealing
Open
Input Voltage
480V AC
Frequency
50/60 Hz
For Use With
Conveyor and Material Handling Applications, Electric Heater, Pumping
Coil Voltage
480V AC
Current Rating
30 A
Horsepower @ 120V AC
2 hp
Base Shape
Square
Power Consumption
10 VA
Maximum Switching Voltage
600V AC
Series
8501C Series
Status Indicator
None
Mounting Type
panel mounting
Contact Rating
30 A
Operating Temp. Range
-22-122°F
Switching Voltage
600 V AC

Description

Open Power Relay, Base Shape Square, Coil Voltage 480V AC, Contact Form SPST-NC, Current Rating 30 A, Electrical Connection Screw Clamp, Flat Pin Width Not Applicable, Number of Pins 4, Sealing Open, Status Indicator No Indicator, Contact Rating (AC) 30 A @ 300V, Horsepower @ 120V AC 2 hp, Horsepower @ 240V AC 2 hp, Mounting Style Through Panel, Body Depth 1.07 in, Body Height 2.49 in, Body Width 2.5 in, Contact Material Copper, Features Durable Open-Frame Construction, Green Premium Product
