Schneider Electric

Pilot Light 24V 8Mm +Options

product price: $35.79
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Voltage 24V
  • Color Red
  • Lamp Type Covered LED
  • Terminal Connection Tag for Faston connectors & Soldering connectors
  • Contact Form (X1-X2)PL
See all product information

Product Information

Dimensions

Width 10 mm
Length 36 mm
Height 10 mm
Depth 1.42 in (36 mm)
Mounting Diameter 0.31 in (8 mm)

Details

Item Pilot Light
Voltage 24V
Color Red
Lamp Type Covered LED
Terminal Connection Tag for Faston connectors & Soldering connectors
Contact Form (X1-X2)PL
IP Rating IP65/IP40
Average Life 100000 hr
Standards CSA; UL
IP Degree Of Protection IP65 IEC 60529 with seal XVLZ911; IP65 NF C 20-010 with seal XVLZ911; IP40 IEC 60529; IP40 NF C 20-010
Connections - Terminals Tag for Faston connectors 2.8 x 0.5 mm; Tag for soldering connectors
Supply Circuit Type DC
Protection Type Built-in by diode; Integral ballast resistor
Component Name XVL
Nominal Voltage Limit 0.8 to 1.1 Un
Product Or Component Type LED pilot light with integral lens cap
Rated Insulation Voltage 50 V IEC 60947-1
Bulb Lifespan 100000 h
Ambient Air Temperature For Operation -13 to 158°F (-25 to 70°C)
Rated Supply Voltage 24 V
Current Consumption 18 mA
Protective Treatment TC
Overvoltage Category Class 3 IEC 60536; Class 3 NF C 20-030
Ambient Air Temperature For Storage -40 to 158°F (-40 to 70°C)
Lamp Color Red
Series XVL

Description

Pilot Light
