  15. Pilot light, Harmony XVL, plastic, green, 12mm, covered LED, 12V DC
Schneider Electric Pilot light, Harmony XVL, plastic, green, 12mm, covered LED, 12V DC XVLA323 - main

Pilot light, Harmony XVL, plastic, green, 12mm, covered LED, 12V DC

  • Mfr # XVLA323

  • Zoro # G0858159

product price: $50.79
/ea

Key Features

Voltage
12V
Color
Green
Lamp Type
Covered LED
Terminal Connection
Threaded connector
Contact Form
(X1-X2)PL
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XVLA323
Zoro #
G0858159
UPC #
785901779094
Country of Origin
Spain

Dimensions

Height
16 mm
Length
51 mm
Width
16 mm
Mounting Diameter
12 mm

Details

Item
Pilot Light 12V 12Mm +Options
Voltage
12V
Color
Green
Lamp Type
Covered LED
Terminal Connection
Threaded connector
Contact Form
(X1-X2)PL
Standards
UL; CSA
IP Rating
IP65/IP40
Average Life
100000 hr
Nominal Voltage Limit
0.8...1.1 Un
Connections - Terminals
threaded connector 1 x 0.2...1 x 1.5 mm²
Component Name
XVL
[Ui] Rated Insulation Voltage
50 V IEC 60947-1
Product or Component Type
LED pilot light with integral lens cap
Supply Circuit Type
DC
Protective Treatment
TC
Ambient Air Temperature For Operation
-25-70°C
Overvoltage Category
class 3 IEC 60536, class 3 NF C 20-030
Bulb Lifespan
100000 h
Ambient Air Temperature For Storage
-40-70°C
Range of Product
Harmony XVL
[Us] Rated Supply Voltage
12 V
Ip Degree of Protection
IP65 IEC 60529 with seal XVLZ912), IP65 NF C 20-010 with seal XVLZ912), IP40 IEC 60529, IP40 NF C 20-010
Protection Type
built-in by diode, integral ballast resistor
Current Consumption
18 mA

Description

Pilot Light 12V 12Mm +Options
