  13. Plug in relay, Harmony Solid State Slim Relays, 3.5A, DC switching, input 15 to 30V DC, output 1 to 24V DC
Schneider Electric Plug in relay, Harmony Solid State Slim Relays, 3.5A, DC switching, input 15 to 30V DC, output 1 to 24V DC SSL1D03BD - main

Plug in relay, Harmony Solid State Slim Relays, 3.5A, DC switching, input 15 to 30V DC, output 1 to 24V DC

  • Mfr # SSL1D03BD

  • Zoro # G7331426

product price: $24.29
/ea

Key Features

Standards
UL, CSA
Response Time
0.35 ms (turn-on), 0.08 ms (turn-off)
Width
5 mm
Height
28 mm
Depth
15 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SSL1D03BD
Zoro #
G7331426
UPC #
-
Country of Origin
Mexico

Dimensions

Width
5 mm
Height
28 mm
Depth
15 mm

Details

Standards
UL, CSA
Response Time
0.35 ms (turn-on), 0.08 ms (turn-off)
Item
SsrSlim,1 Channel 3.5A@1-24VDC,15-30VDC
Dielectric Strength
2500 V for input/output
Product or Component Type
solid state relay up to 10 A
Capacitance Unbalance
1.5 pF input/output
Overvoltage Category
III
Load Current
0.001-3.5 A
Ambient Air Temperature For Storage
-20-85°C
Range of Product
Harmony Solid State Relays
Mounting Support
socket
Pollution Degree
2
Surge Current
9 A 10 ms
Marking
CE
Input Current Limits
7-7 mA
Absolute Maximum Voltage
30 V DC
Maximum Voltage Drop
<0.5 V on-state
Solid State Output Type
Mosfet output, DC switching
Line Rated Current
3.5 A
[Uc] Control Circuit Voltage
15...30 V DC
Output Switching Mode
DC switching
Input Impedance
3500 Ohm
Maximum Operating Frequency
500 Hz
Phase
1 phase
Minimum Switching Voltage
15 V DC turn-on
Maximum Leakage Current
0.001 mA off-state
Device Short Name
SSL
Maximum Switching Voltage
10 V DC turn-off
Ambient Air Temperature For Operation
-20-80°C
Output Voltage
1...24 V DC
Flame Retardance
V0 conforming to UL 94
Product Certifications
UL || CSA
Product Or Component Type
solid state relay up to 10 A

Description

This Harmony SSL slim interfacing solid state plug-in relay is rated 3.5A, is controlled with a 15V to 30V DC input, has a rated load voltage of 1V to 24V DC with DC switching. It is 6mm width, including socket, to save space in your control cabinets. It is also silent and reliable thanks to the absence of moving contacts. It is shock, vibration and pollution resistant thanks to its IP67, it makes it ideal for harsh industrial environments.
