  15. Push Button Operator, 30 mm, 2NO/2NC, Blue
Schneider Electric Push Button Operator, 30 mm, 2NO/2NC, Blue 9001KXRALH2 - main

Push Button Operator, 30 mm, 2NO/2NC, Blue

  • Mfr # 9001KXRALH2

  • Zoro # G3462226

product price: $131.99
/ea
Free Shipping & Returns

Key Features

Push Button Style
Extended
Action
Momentary
Operator Illumination
Non-Illuminated
Panel Cutout Diameter
30 mm
Head Color
Blue
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001KXRALH2
Zoro #
G3462226
UPC #
785901146971
Country of Origin
Mexico

Dimensions

Panel Cutout Diameter
30 mm
Size
30 mm
Manufacturer Warranty Length
18 mo

Details

Item
Push Button Operator
Push Button Style
Extended
Action
Momentary
Operator Illumination
Non-Illuminated
Head Color
Blue
Head Material
Metal
Terminal Connection
Screw Clamp
Standards
REACH, RoHS, WEEE
Contact Form
2NO/2NC
Number of Operators
1
Bezel Material
Metal
Features
Self-Grounding, Finger-Safe Terminals
AC Contact Rating
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Color
Blue
Contact Rating
10A @ 600V AC
DC Contact Rating
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
IP Rating
IP20, IP66
Legend/Background Color
No Legend
Series
9001K
Product Type
Push Button Operators
Operator Material
Metal
Operating Temperature - Maximum
140 Degrees F
Operator Voltage Rating - Maximum
600 V AC
Hazardous Location Specification
Class I, Div 2, Group A, B, C, D, Class II, Div 2, Group E, F, G, Class III, Div 1 and 2
Operating Temperature - Minimum
-22 Degrees F
Number of Indicator Lights
0
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4

Description

Extended Push Button Operator, 30 mm, Momentary Action, Head Material Metal, Contact Form 2NO/2NC, Color Blue, Contact Rating 10A @ 600V AC, Number of Operators 1, IP Rating IP20, IP66, Legend Not Applicable, Legend/Background Color No Legend, Standards REACH, RoHS, WEEE, Terminal Connection Screw Clamp, Features Self-Grounding, Finger-Safe Terminals
