  15. Push Button with Transmitter, 22 mm, Green
Schneider Electric Push Button with Transmitter, 22 mm, Green ZB4RTA3 - main

Push Button with Transmitter, 22 mm, Green

  • Mfr # ZB4RTA3

  • Zoro # G4205092

product price: $125.99
/ea
Free Shipping & Returns

Key Features

Push Button Style
Flush
Action
Momentary
Operator Illumination
Non-Illuminated
Panel Cutout Diameter
22 mm
Head Color
Green
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZB4RTA3
Zoro #
G4205092
UPC #
785901705352
Country of Origin
France

Dimensions

Panel Cutout Diameter
22 mm
Size
22 mm
Height
1.3 in
Width
3.39 in
Length
2.05 in
Length (Straight Wireway)
2.05 in
Cad Overall Height
41.5 mm
Mounting Diameter
22 mm
Cad Overall Depth
43 mm
Bandwidth
5-5 MHz
Cad Overall Width
30 mm
Embedding Depth
42 mm
Manufacturer Warranty Length
18 mo
Overall Depth
2.05 in
Overall Height
1.82 in
Overall Width
1.18 in

Details

Item
Wireless Push Button Transmitter
Push Button Style
Flush
Action
Momentary
Operator Illumination
Non-Illuminated
Head Color
Green
Head Material
Metal
Standards
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
Type of Operator
Flush Push Button
Legend Markings
No Legend
IP Rating
IP30
Material
Metal
NEMA Rating
12
Number of Operators
1
Color
Green
Series
XB4R
Legend
None
Bezel Material
chromium plated metal
Product Certifications
BT 2006/95/EC || C-tick || CCC || UL || GOST || CSA
Operator Profile
green flush
Mechanical Durability
1000000 cycles
Level Or Class
5M00G7W
Fixing Mode
fixing screw beneath head 0.8-1.2 N.m
Electromagnetic Compatibility
electrostatic discharge immunity test 8 kV in free air (in insulating parts)) IEC 61000-4-2 || electrostatic discharge immunity test 4 kV on contact (on metal parts)) IEC 61000-4-2 || susceptibility to electromagnetic fields 20 V/m 80 to 3000 MHz) IEC 61000-4-3 || susceptibility to electromagnetic fields 6 V/m 3000 to 6000 MHz, distance = 20 m) IEC 61000-4-3
Shape Of Signaling Unit Head
round
Protective Treatment
TH
Number Of Channels
16
Fixing Collar Material
zamak
Radio Agreement
ANATEL || ARIB T66 || FCC || ICASA || RSS
Modulation Technique
O-QPSK
Operating Force
10 N C/O changing electrical state
Max Power Consumption In W
1 mW
Ik Degree Of Protection
IK03 IEC 50102
Response Time
< 2 ms
Antenna Type
omnidirectional
Ambient Air Temperature For Operation
-40-70°C
Device Short Name
XB5R
Antenna Gain
0 dBi
Ambient Air Temperature For Storage
-40-70°C
Communication Port Protocol
Zigbee green power 2.4 GHz IEEE 802.15.4
Relative Humidity
95-95 % -40-70°C without condensation
Maximum Sensing Distance
100 m in free field || 25 m transmitter in a plastic box type XAL D and receiver in a metal enclosure || 300 m transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna
Shock Resistance
25 gn 6 ms) 6000 shocks IEC 60068-2-27 || 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Product Or Component Type
wireless and batteryless transmitter
Ip Degree Of Protection
IP66 IEC 60529 front face) || IP67 IEC 60529 front face) || IP69 IEC 60529 front face) || IP69K IEC 60529 front face)
Operating Travel
4.3 mm total travel)
Emission Power
3 mW
Transmission Frequency
2405 MHz
Mechanical Robustness
free fall resistance 1000 mm EN/IEC 60068-2-32
Acquisition Time
2 ms
Electrical Composition Code
PW1
Vibration Resistance
5 gn 11-500 Hz)IEC 60068-2-6 || +/- 10 mm 2-11 Hz)IEC 60068-2-6
Mechanical Operating Durability
1,000,000
NEMA Enclosure Rating
12
Operating Temperature - Minimum
-40 Degrees F
Operator Material
Metal
Resistance Properties
Shock Resistant, Vibration Resistant
Operating Temperature - Maximum
158 Degrees F

Description

Wireless Push Button Transmitter, Color Green, Action Momentary, Material Metal, NEMA Rating 12, IP Rating IP30, Number of Operators 1, Size 22 mm, Type of Operator Flush Push Button, Height 1.3 in, Width 3.39 in, Length 2.05 in, Legend Markings No Legend, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
