Shop SCHNEIDER ELECTRIC

Slim Interface Relay Socket, 6 A, 5 Pins

  • Mfr # SSLZRA1

  • Zoro # G3462953

product price:  $8.79
/ea
Sold in multiples of 10 for $87.90

Key Features

Item - Relay
Relay Socket
Contact Form - Relay Socket
SPDT
Mounting - Relay
DIN Rail
Color
Black
Body Height - Relay
3.09 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SSLZRA1
Zoro #
G3462953
UPC #
785901968344
Country of Origin
China

Dimensions

Body Height - Relay
3.09 in
Body Depth - Relay
3.98 in
Width
0.24 in
Body Width - Relay
0.24 in
Height - Relay Socket
3.09"
Depth
3.09 in
Height
3.98 in

Details

Item - Relay
Relay Socket
Contact Form - Relay Socket
SPDT
Mounting - Relay
DIN Rail
Color
Black
Standards
CSA C22-2 No 14, IEC 61984, UL 508
Contact Form - Relay
SPDT
Number of Pins
5
Socket Type
Standard
Socket Supply Voltage
5V DC
Contact Form
SPDT
Status Indicator
LED Indicator
Item
Slim Interface Relay Socket
Dielectric Strength
2,500V
Contact Terminal Arrangement
Separate
Current Rating
6 A
Contact Rating (DC)
6 A @ 250V
Mounting Style
DIN Rail
Compatible Relays
SSL 24 V DC, SSL 5 V DC
IP Rating
IP20
Pin Shape
Flat
Base Style
Square
Maximum Operating Temperature
158 Degrees F
Minimum Operating Temperature
-40 Degrees F
Compatible with Manufacturer Model Number
SSLZVA1
Weight
0.96 oz
Electrical Connection
Spring Terminal
Compatible Manufacturer Part Number
SSLZVA1
Compatible Manufacturer Model Number
SSLZVA1
For Use With Mfr. Model Number
SSLZVA1
Ip Degree Of Protection
IP20
Product Compatibility
solid state relay SSL NO 24 V DC || solid state relay SSL NO 5 V DC
Connections - Terminals
spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) solid without cable end || spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) flexible with cable end
Shape Of Pin
flat
Ambient Air Temperature For Operation
-40-70°C
[Ue] Rated Operational Voltage
< 250 V DC
Product Certifications
UL 508 || CSA C22-2 No 14
Overvoltage Category
III
Marking
CE
Product Or Component Type
socket for SSL1
Clamping Force
10-40 N
Device Short Name
SSLZ
Local Signalling
for input status LED (green)
Flame Retardance
V0 conforming to UL 94
Ambient Air Temperature For Storage
-40-85°C
Fixing Mode
clip-on 35 mm DIN rail)
Switching Voltage
5 V DC || 24 V DC
[Ith] Conventional Free Air Thermal Current
6A
Pollution Degree
3
[Uimp] Rated Impulse Withstand Voltage
3.6 kV
Compatible with Manufacturer Model No.
SSLZVA1
Compatible with Mfr. Model No.
SSLZVA1
For Use with Mfr Model Number
SSLZVA1
Compatible Pump Manufacturer Part Number
SSLZVA1
Compatible Mfr. Model Number
SSLZVA1
For Manufacturer Part Number
SSLZVA1
Compatible with Mfr. Model Number
SSLZVA1

Description

Slim Interface Relay Socket, Base Style Square, Compatible Relays SSL 24 V DC, SSL 5 V DC, Contact Form SPDT, Current Rating 6 A, Electrical Connection Spring Terminal, Number of Pins 5, Pin Shape Flat, Socket Type Standard, Contact Terminal Arrangement Separate, Mounting Style DIN Rail, Color Black, Compatible with Manufacturer Model Number SSLZVA1, Contact Rating (DC) 6 A @ 250V, Depth 3.09 in, Dielectric Strength 2,500V, Height 3.98 in, IP Rating IP20
