  13. Socket, General Purpose Relay, Octal, 12 A, 8 Pins, Pin
Schneider Electric Socket, General Purpose Relay, Octal, 12 A, 8 Pins, Pin 750XBXH-12D - main

Socket, General Purpose Relay, Octal, 12 A, 8 Pins, Pin

  • Mfr # 750XBXH-12D

  • Zoro # G0561775

product price: $136.99
/ea
Free Shipping & Returns

Key Features

Mounting Style
Socket
Electrical Connection
Pin
Base Shape
Octal
Number of Pins
8
Coil Voltage
12V DC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
750XBXH-12D
Zoro #
G0561775
UPC #
-
Country of Origin
China

Dimensions

Overall Height - Relay
2.1 in
Overall Depth
2.07 in
Body Height
1.62 in
Body Depth
2.07 in
Body Width
1.44 in
Width
1.44 in (36.5 mm)
Depth
1.62 in (41.2 mm)

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Pin
Base Shape
Octal
Number of Pins
8
Coil Voltage
12V DC
Current Rating
12 A
Contact Form
DPDT
Contact Rating (AC)
12 A @ 120V, 12 A @ 240V
Contact Rating (DC)
12 A @ 28V
Status Indicator
No Indicator
Socket Code
A
Power Consumption - Relay
2 W
Contact Material
Silver Alloy
Socket
Mfr. No. 70-464-1, 70-750E8-1
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Standards
CSA Certified, UL Listed
Power Consumption
1.2 W
Motor Rated
Yes
Input Voltage
12V DC
Operating Current
12 A at 120V AC (Conforming to UL), 12 A at 240V AC (Conforming to UL), 12 A at 28V DC (Conforming to UL)
Minimum Switching Current
100 mA
Push-To-Test Method
No Test Button
Sealing
Enclosed
Maximum Switching Voltage
300V
Minimum Operating Temperature
-40 Degrees F
Electrical Operating Durability
100,000
Maximum Operating Temperature
131 Degrees F
Mechanical Operating Durability
10,000,000
Resistance Properties
Shock-Resistant, Vibration-Resistant
Weight
4.59 oz
Dielectric Strength
1,500V AC Between Open Contacts, 1,600V AC Between Coil and Contact, 1,600V AC Between Poles
Response Time
20 msec
Series
750H Haz Location Series
IP Rating
IP67
Horsepower @ 240V AC
1/2 hp
Coil Resistance
120 ohm
Horsepower @ 120V AC
1/3 hp
Pin Shape
Round
Power consumption in W
1.2 W DC
Voltage Range
0.8...1.1 Un AC/DC
Connections Terminals
octal terminal 8 pins)
Shock Resistance
10 gn
Ambient Air Temperature for Operation
-40 to 131°F (-40 to 55°C)
Drop-out Voltage Threshold
>= 0.15 Uc AC; >= 0.1 Uc DC
Motor Power HP
0.5 hp 240 V AC 50/60 Hz; 0.33 hp 120 V AC 50/60 Hz
Contact Composition
2 NC + 2 NO
Ambient Air Temperature for Storage
-40 to 185°F (-40 to 85°C)
Product Certifications
UL; CSA
Operating Time
20 ms
Vibration Resistance
3 gn 35 to 150 Hz)operating; +/- 1 mm 10 to 35 Hz)operating; 6 gn 35 to 150 Hz)not operating; +/- 1 mm 10 to 35 Hz)not operating

Description

Hermetically Sealed Relay, Base Shape Octal, Coil Voltage 12V DC, Contact Form DPDT, Current Rating 12 A, Electrical Connection 8-Pin Terminal, Flat Pin Width Not Applicable, Number of Pins 8, Pin Shape Round, Sealing Enclosed, Status Indicator No Indicator, Contact Rating (AC) 12 A @ 120V, 12 A @ 240V, Contact Rating (DC) 12 A @ 28V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC 1/2 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 2.07 in, Body Height 1.62 in
