Socket, General Purpose Relay, Octal, 12 A, 8 Pins, Pin

  • Mfr # 750XBXH-24A

  • Zoro # G0450581

product price:
$
156.27
/ea
Free Shipping & Returns

Key Features

Mounting Style
Socket
Electrical Connection
Pin
Base Shape
Octal
Number of Pins
8
Coil Voltage
24V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
750XBXH-24A
Zoro #
G0450581
UPC #
-
Country of Origin
China
Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Pin
Base Shape
Octal
Number of Pins
8
Coil Voltage
24V AC
Current Rating
12 A
Contact Form
DPDT
Contact Rating (AC)
12 A @ 120V, 12 A @ 240V
Contact Rating (DC)
12 A @ 28V
Power Consumption - Relay
2 VA
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Socket
Mfr. No. 70-464-1, 70-750E8-1
Socket Code
A
Standards
CSA Certified, UL Listed
Contact Material
Silver Alloy
Status Indicator
No Indicator
Mechanical Operating Durability
10,000,000
Motor Rated
Yes
Maximum Operating Temperature
131 Degrees F
Series
750H Haz Location Series
Dielectric Strength
1,500V AC Between Open Contacts, 1,600V AC Between Coil and Contact, 1,600V AC Between Poles
Resistance Properties
Shock-Resistant, Vibration-Resistant
Maximum Switching Voltage
300V
Pin Shape
Round
Sealing
Enclosed
Power Consumption
1.2 W, 2.75 VA
Coil Resistance
72 ohm
Input Voltage
24V AC
Horsepower @ 240V AC
1/2 hp
Operating Current
12 A at 120V AC (Conforming to UL), 12 A at 240V AC (Conforming to UL), 12 A at 28V DC (Conforming to UL)
Weight
4.59 oz
Minimum Operating Temperature
-40 Degrees F
Minimum Switching Current
100 mA
Horsepower @ 120V AC
1/3 hp
IP Rating
IP67
Response Time
20 msec
Electrical Operating Durability
100,000
Push-To-Test Method
No Button
Power consumption in W
1.2 W DC
Drop-out Voltage Threshold
>= 0.15 Uc AC; >= 0.1 Uc DC
Contact Composition
2 NC + 2 NO
Connections Terminals
octal terminal 8 pins)
Power consumption in VA
2.75 VA AC
Product Certifications
UL; CSA
Motor Power HP
0.5 hp 240 V AC 50/60 Hz; 0.33 hp 120 V AC 50/60 Hz
Ambient Air Temperature for Operation
-40 to 131°F (-40 to 55°C)
Operating Time
20 ms
Voltage Range
0.85...1.1 Un AC/DC
Ambient Air Temperature for Storage
-40 to 185°F (-40 to 85°C)
Vibration Resistance
3 gn 35 to 150 Hz)operating; +/- 1 mm 10 to 35 Hz)operating; 6 gn 35 to 150 Hz)not operating; +/- 1 mm 10 to 35 Hz)not operating
Shock Resistance
10 gn

Description

Hermetically Sealed Relay, Base Shape Octal, Coil Voltage 24V AC, Contact Form DPDT, Current Rating 12 A, Electrical Connection 8-Pin Terminal, Flat Pin Width Not Applicable, Number of Pins 8, Pin Shape Round, Sealing Enclosed, Status Indicator No Indicator, Contact Rating (AC) 12 A @ 120V, 12 A @ 240V, Contact Rating (DC) 12 A @ 28V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC 1/2 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 2.07 in, Body Height 1.62 in
