  7. Socket, General Purpose Relay, Square, 15 A, 5 Pins, Faston Connector
Schneider Electric Socket, General Purpose Relay, Square, 15 A, 5 Pins, Faston Connector 781XAXRM4L-12D - main

Socket, General Purpose Relay, Square, 15 A, 5 Pins, Faston Connector

  • Mfr # 781XAXRM4L-12D

  • Zoro # G0088691

product price:  $14.29
/ea

Key Features

Mounting Style
Socket
Electrical Connection
Faston Connector
Base Shape
Square
Number of Pins
5
Coil Voltage
12V DC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
781XAXRM4L-12D
Zoro #
G0088691
UPC #
-
Country of Origin
China

Dimensions

Overall Height - Relay
1.57 in
Body Height
1.07 in
Body Width
0.53 in
Overall Depth
1.57 in
Body Depth
1.57 in
Depth
1.07 in (27.3 mm)
Width
0.83 in (21 mm)

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Faston Connector
Base Shape
Square
Number of Pins
5
Coil Voltage
12V DC
Current Rating
15 A
Contact Form
SPDT
Contact Rating (AC)
10 A @ 151/277V, 15 A @ 120 to 277/120/150/250V, 7.55 A @ 250V
Contact Rating (DC)
15 A @ 28V (NO), 7.55 A @ 28V (NC)
Power Consumption - Relay
1.4 W
Standards
CE Certified, CSA Certified, UL Listed
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Socket
Mfr. No. 70-781D5R-1A, 70-781D5, 70-781D
Status Indicator
LED Indicator, Mechanical Flag
Socket Code
L
Contact Material
Gold Flashed Silver Alloy
IP Rating
IP40
Minimum Operating Temperature
-40 Degrees F
Maximum Operating Temperature
131 Degrees F
Horsepower @ 120V AC
1/2 hp
Coil Resistance
115 ohm
Minimum Switching Current
10 mA
Frequency
50/60 Hz
Operating Current
10 A at 151/277V, 15 A at 120 to 277V, 15 A at 120/150V, 15 A at 250V, 15 A at 28V, 15 A at 28V (NO), 7.55 A at 250V (NC), 7.55 A at 28V (NC)
Mechanical Operating Durability
10,000,000
Horsepower @ 240V AC
1 hp
Push-To-Test Method
Lockable
Input Voltage
12V DC
Electrical Operating Durability
100,000
Resistance Properties
Shock-Resistant, Vibration-Resistant
Maximum Switching Voltage
250V AC, 300V DC
Response Time
25 msec
Weight
1.02 oz
Series
781R Series
Motor Rated
Yes
For Use With
Automation Panels and Controls
Power Consumption
1.4 W, 1.9 VA
Dielectric Strength
1,500V AC Between Contacts, 2,000V AC Between Coil and Contact, 2,000V AC Between Poles
Motor Power HP
0.5 hp 120 V AC 50-60 Hz; 1 hp 277 V AC 50-60 Hz
Power consumption in W
1.4 W DC
Control Type
Lockable test button
Vibration Resistance
+/-1 mm 10 to 35 Hz); 3 gn 35 to 150 Hz)
Voltage Range
0.8...1.1 Un AC/DC
Power consumption in VA
1.9 VA AC
Operating Time
20 ms operating; 20 ms tripping
Contact Composition
1 NC + 1 NO
Shock Resistance
15 gn in operation
Drop-out Voltage Threshold
>= 0.15 Uc AC; >= 0.1 Uc DC
Ambient Air Temperature for Storage
-40 to 185°F (-40 to 85°C)
Ambient Air Temperature for Operation
-40 to 131°F (-40 to 55°C)
Product Range
Legacy
Connections Terminals
Faston terminals
Product Certifications
UL; CE; CSA

Description

General Purpose Relay, Base Shape Square, Coil Voltage 12V DC, Contact Form SPDT, Current Rating 15 A, Electrical Connection Faston Terminal, Number of Pins 5, Status Indicator LED Indicator, Mechanical Flag, Contact Rating (AC) 10 A @ 151/277V, 15 A @ 120 to 277/120/150/250V (NO), 7.55 A @ 250V (NC), Contact Rating (DC) 15 A @ 28V (NO), 7.55 A @ 28V (NC), Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1 hp, Mounting Style Socket, Push-To-Test Method Lockable, Body Depth 1.57 in
