  13. Socket, General Purpose Relay, Square, 15 A, 5 Pins, Faston Connector
Schneider Electric Socket, General Purpose Relay, Square, 15 A, 5 Pins, Faston Connector 781XAXRM4L-24A - main

CAD Viewer & Download Files

Socket, General Purpose Relay, Square, 15 A, 5 Pins, Faston Connector

  • Mfr # 781XAXRM4L-24A

  • Zoro # G0059206

CAD Available
product price: $11.55
/ea

Key Features

CAD Drawing
Mounting Style
Socket
Electrical Connection
Faston Connector
Base Shape
Square
Number of Pins
5
Coil Voltage
24V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
781XAXRM4L-24A
Zoro #
G0059206
UPC #
-
Country of Origin
China

Dimensions

Overall Height - Relay
1.57 in
Overall Depth
1.57 in
Body Depth
1.57 in
Body Width
0.53 in
Body Height
1.07 in
Depth
1.07 in (27.3 mm)
Width
0.83 in (21 mm)

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Faston Connector
Base Shape
Square
Number of Pins
5
Coil Voltage
24V AC
Current Rating
15 A
Contact Form
SPDT
Contact Rating (AC)
10 A @ 151/277V, 15 A @ 120 to 277/120/150/250V, 7.55 A @ 250V
Contact Rating (DC)
15 A @ 28V (NO), 7.55 A @ 28V (NC)
Socket
Mfr. No. 70-781D5R-1A, 70-781D5, 70-781D
Standards
CE Certified, CSA Certified, UL Listed
Status Indicator
LED and Mechanical Flag
Power Consumption - Relay
1.9 VA
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Socket Code
L
Contact Material
Gold Flashed Silver Alloy
Electrical Operating Durability
100,000
Maximum Operating Temperature
131 Degrees F
Frequency
50/60 Hz
Input Voltage
24V AC
Resistance Properties
Shock-Resistant, Vibration-Resistant
Mechanical Operating Durability
10,000,000
For Use With
Automation Panels and Controls
Series
781R Series
Motor Rated
Yes
IP Rating
IP40
Operating Current
10 A at 151/277V, 15 A at 120 to 277V, 15 A at 120/150V, 15 A at 250V, 15 A at 28V, 15 A at 28V (NO), 7.55 A at 250V (NC), 7.55 A at 28V (NC)
Maximum Switching Voltage
250V AC, 300V DC
Horsepower @ 240V AC
1 hp
Response Time
25 msec
Dielectric Strength
1,500V AC Between Contacts, 2,000V AC Between Coil and Contact, 2,000V AC Between Poles
Minimum Operating Temperature
-40 Degrees F
Push-To-Test Method
Lockable Push Test Button
Coil Resistance
177 ohm
Horsepower @ 120V AC
1/2 hp
Minimum Switching Current
10 mA
Power Consumption
1.4 W, 1.9 VA
Weight
1.02 oz
Operating Time
20 ms operating; 20 ms tripping
Ambient Air Temperature for Storage
-40 to 185°F (-40 to 85°C)
Control Type
Lockable test button
Drop-out Voltage Threshold
>= 0.15 Uc AC; >= 0.1 Uc DC
Contact Composition
1 NC + 1 NO
Voltage Range
0.8...1.1 Un AC/DC
Power consumption in W
1.4 W DC
Ambient Air Temperature for Operation
-40 to 131°F (-40 to 55°C)
Shock Resistance
15 gn in operation
Motor Power HP
0.5 hp 120 V AC 50-60 Hz; 1 hp 277 V AC 50-60 Hz
Product Certifications
UL; CE; CSA
Connections Terminals
Faston terminals
Product Range
Legacy
Vibration Resistance
+/-1 mm 10 to 35 Hz); 3 gn 35 to 150 Hz)
Power consumption in VA
1.9 VA AC
CAD Available
Yes

Description

General Purpose Relay, Base Shape Square, Coil Voltage 24V AC, Contact Form SPDT, Current Rating 15 A, Electrical Connection Faston Terminal, Number of Pins 5, Status Indicator LED Indicator, Mechanical Flag, Contact Rating (AC) 10 A @ 151/277V, 15 A @ 120 to 277/120/150/250V (NO), 7.55 A @ 250V (NC), Contact Rating (DC) 15 A @ 28V (NO), 7.55 A @ 28V (NC), Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1 hp, Mounting Style Socket, Push-To-Test Method Lockable, Body Depth 1.57 in
