Socket, Plug-In Relay, 6 A, Pin

Plug-In Relay

Socket

Pin

12V DC

6 A

6 A @ 250V AC

6 A @ 28V DC

Lockable Test Button; Status LED

AgNi

0.9 W

CSA C22.2 No 14; EN/IEC 61810-1; UL 508; CE; GOST; Lloyd's

20 ms

flat

1300 V AC between contacts with micro disconnection; 2000 V AC between coil and contact with basic insulation; 2000 V AC between poles with basic insulation

250 V IEC

160 Ohm

RXM; Miniature

RT I

Max 1500 VA/168 W; Min 170 mW 10 mA, 17 V

-40-55°C

9.6...13.2 V DC

Miniature

<= 1200 cycles/hour under load, <= 18000 cycles/hour no-load

170 mW 10 mA, 17 V

5A

2

-40-85°C

IP40 conforming to IEC 60529

0.2

any position

1500 VA/168 W

160 Ohm 20°C +/- 10 %

3 gn +/- 1 mm 10-150 Hz)5 cycles in operation, 5 gn +/- 1 mm 10-150 Hz)5 cycles not operating

6 A 250 V AC, 6 A 28 V DC

lockable test button

250 V IEC, 300 V CSA, 300 V UL

10000000 cycles

10 gnin operation, 30 gnnot operating

>= 0.1 Uc

level A group mounting

2.5 kV 1.2/50µs

RXM

complete product

100000 cycles resistive

-40-55°C

LED Indicator
