Shop SCHNEIDER ELECTRIC

Solid State Relay, 1 Phase, Pin, Socket, Transistor

  • Mfr # SSL1D101BD

  • Zoro # G0745668

product price:  $12.29
/ea

Key Features

Electrical Phase
1
Electrical Connection
Pin
Mounting Style
Socket
Switch Component Type
Transistor
Case Color
Black
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
SSL1D101BD
Zoro #
G0745668
UPC #
785901968207
Country of Origin
China

Dimensions

Overall Height - Relay
0.74 in
Body Width
0.2 in
Body Height
1.1 in
Overall Depth
0.74 in
Body Depth
0.59 in
Height
28 mm
Depth
15 mm
Width
5 mm

Details

Item
Solid State Relay
Electrical Phase
1
Electrical Connection
Pin
Mounting Style
Socket
Switch Component Type
Transistor
Case Color
Black
Input Voltage
16 to 30V DC
Standards
CE Certified, CSA Certified, UL Listed
Contact Form - Relay
SPST-NO
Includes
LED Indicator for Easy Identification of Control Status
Current Rating
0.1 A
Weight
0.16 oz
Minimum Operating Temperature
-4 Degrees F
Maximum Operating Temperature
176 Degrees F
Response Time
0.02 msec
Maximum Switching Voltage
9V DC
Minimum Switching Voltage
16V DC
Product Certifications
CSA || UL
Pollution Degree
2
Maximum Leakage Current
0.001 mA off-state
Capacitance Unbalance
1.5 pF input/output
Device Short Name
SSL
Output switching mode
DC switching
Ambient Air Temperature For Operation
-20-80°C
Overvoltage Category
III
Input Impedance
3500 Ohm
Maximum Operating Frequency
500 Hz
Load Current
0.001-0.1 A
Flame Retardance
V0 conforming to UL 94
Input Current Limits
5-5 mA
Solid State Output Type
DC switching || transistor output
Marking
CE
Ambient Air Temperature For Storage
-20-85°C
Maximum Voltage Drop
<1 V on-state
Surge Current
0.3 A 10 ms
Absolute Maximum Voltage
60 V DC
Dielectric Strength
3750 V for input/output
Maximum Output Current with Heat Sink
0.1 A
Output Voltage Range
1 to 48V DC

Description

Solid State Relay, Coil Voltage 16 to 30V DC, Contact Form SPST-NO, Current Rating 0.1 A, Electrical Connection Pins, Mounting Style Socket, Body Depth 0.59 in, Body Height 1.1 in, Body Width 0.2 in, Input Voltage 16 to 30V DC, Maximum Operating Temperature 176 Degrees F, Maximum Switching Voltage 9V DC, Minimum Operating Temperature -4 Degrees F, Minimum Switching Voltage 16V DC
