Solid State Relay, 3 Phase, screw, symmetrical DIN rail

Mfr # SSM3A325BDR
Zoro # G5956542

159.99

Sold in multiples of 5 for $799.95

Free Shipping & Returns

Key Features

Electrical Phase

Electrical Connection

Screw

Mounting Style

Symmetrical DIN rail

Standards

UL 508, IEC 60950-1, CSA C22.2 No 14

Input Voltage

4 to 32V DC

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: SSM3A325BDR
Zoro #: G5956542
UPC #: -
Country of Origin: Korea, Republic of

Details

Item: Solid State Relay
Electrical Phase: 3
Electrical Connection: Screw
Mounting Style: Symmetrical DIN rail
Standards: UL 508, IEC 60950-1, CSA C22.2 No 14
Input Voltage: 4 to 32V DC
Dielectric Strength: 4 kV AC for input/output, 4 kV AC for input or output to case
Cos Phi: 0.5-0.5 (with maximum load)
Ip Degree of Protection: IP20
Range of Product: Harmony Solid State Relays
Response Time: 0.5 cycle (turn-off), 0.02 ms (turn-on)
Connections - Terminals: screw terminals 0.2...1.3 mm², AWG 24...AWG 16) input, screw terminals 1.3...5.3 mm², AWG 16...AWG 10) output
Dv/Dt: 500 V/µs off-state at maximum voltage
Pollution Degree: 2
Load Current: 0.1-25 A
Maximum Horse Power Rating: 1 hp 40°C 240 V AC, 2 hp 40°C 380 V AC, 3 hp 40°C 480 V AC
Insulation Resistance: 1000 MOhm
Overvoltage Category: III
Maximum Leakage Current: 0.25 mA off-state
Switching Voltage: 4 V DC turn-on, 1 V DC turn-off
Solid State Output Type: random voltage switching
Capacitance Unbalance: 8 pF for input/output
Maximum Voltage Drop: <1.35 V on-state
Local Signalling: for input status LED (green)
Maximum I²T For Fusing: 410 A².s for 10 ms at 50 Hz, 374 A².s for 8.3 ms at 60 Hz
Marking: CSA, EAC, CE, UL
Absolute Maximum Voltage: 1100 V
Surge Current: 286 A 20 ms 50 Hz, 300 A 16.6 ms 60 Hz
Device Short Name: SSM3
Output Switching Mode: random voltage switching
Input Current Limits: 22-28 mA
Ambient Air Temperature For Storage: -40-100°C
Number of Channels: 3
Tightening Torque: 0.6...0.7 N.m for input, 1.36...1.7 N.m for output
Ambient Air Temperature For Operation: -20-80°C
Number Of Channels: 3
Product Certifications: UL || EAC || CSA
Maximum Output Current with Heat Sink: 25 A
Output Voltage Range: 48 to 600V AC

Description

Ssr3 Ch,25A@48-600VAC,RC,4-32 VDC
