  11. Variable Freq. Drive, 3/4hp, 200 to 240V
Schneider Electric Variable Freq. Drive, 3/4hp, 200 to 240V ATV12P055M2 - main

Variable Freq. Drive, 3/4hp, 200 to 240V

  • Mfr # ATV12P055M2

  • Zoro # G3546436

product price: $291.99
/ea
Free Shipping & Returns

Key Features

For Use With
Motor, Single-phase supply voltage: 200¿240 V 50/60 Hz
Depth
4.02 in
Width
2.83 in
Height
5.63 in
Input Voltage
200 to 240V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ATV12P055M2
Zoro #
G3546436
UPC #
785901847595
Country of Origin
Indonesia

Dimensions

Depth
4.02 in
Width
2.83 in
Height
5.63 in
Overall Depth
4 1/8 in
Overall Width
2 7/8 in
Overall Height
5 5/8 in

Details

Item
Variable Speed Drive
For Use With
Motor, Single-phase supply voltage: 200¿240 V 50/60 Hz
Input Voltage
200 to 240V AC
Application
Commercial Equipment Mixer, Commercial Equipment Other Application, Textile Ironing
Output Frequency Range
0.5 to 400 Hz
With Bypass / No Bypass
No Bypass
Control Method
Quadratic V/Hz, Volts Per Hz, Sensor less Flux Vector Control
Displays
4-Digit LED Display
Input Frequency
50/60 Hz
Max. Output Amps
5.3 A
With Line Contactor / No Line Contactor
No Line Contactor
Adjustable Acceleration Time
0 to 999.9 sec
Output Voltage
200 to 240V AC
Display Type
4-Digit LED
Output Phase AC
Three
Adjustable Deceleration Time
0 to 999.9 sec
Standards
UL, C-tick, NOM, GOST, CSA
Max. HP
0.75 hp
Input Phase AC
Single
Digital Readout
Yes
Enclosure
Open
Dynamic Braking
No
Starting Torque
150% to 170%
Protection
Against Input Phase Loss in Three-Phase, Line Supply Overvoltage, Line Supply Undervoltage, Overcurrent Between Output Phases and Earth, Overheating Protection, Short-Circuit Between Motor phases, Thermal Motor Protection via the Drive by Continuous Calculation of I²t
Start/Stop Control
Programmable
Maximum Output Current
3.5 A
Torque Application
Constant Torque, Variable Torque
Number of Outputs
(1) Analog; (2) Discrete
Maximum Output Power
3/4 hp
Output Voltage Range
200V AC to 240V AC
Output Type
Analog, Discrete
Brake Chopper Included
No
Ethernet Port Included
No
Input Type
Analog, Discrete
Number of Inputs
(2) Analog; (4) Discrete
Input Voltage Range
170 to 264V AC
Series
Altivar 12
Enclosure Rating
NEMA 1
Style
Base Plate
Color
Black

Description

Variable Speed Drive, Input Voltage 200 to 240V AC, Input Phase AC Single, Input Frequency 50/60 Hz, Maximum Output Power 3/4 hp, Maximum Output Current 3.5 A, Output Voltage 200 to 240V AC, Output Phase AC Three, Output Frequency Range 0.5 to 400 Hz, Enclosure Rating NEMA 1
