Flange Bearing, 4-Bolt, Ball, 1-1/2" Bore
Mfr # MSF-24
Zoro # G7963864
product price:Â
$
299.99
/ea
Free Shipping & Returns
Key Features
System of Measurement
Inch
Housing Type
Square
Number of Mount Holes
4
Bearing Insert Type
Radial Ball
Shaft Locking Type
Set Screw
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- MSF-24
- Zoro #
- G7963864
- UPC #
- -
- Country of Origin
- Multiple
Dimensions
- Bolt Size
- 9/16 in
- Bore Diameter
- 1-1/2 in
- Mount Hole Center-to-Center Length
- 4-1/8 in
- Overall Length
- 5-13/32 in
- Overall Width
- 2-1/16 in
- Overall Height
- 5-13/32 in
- Flange Thickness
- 9/16 in
- Dimension L
- 2 19/64 in
- Dimension E
- 2 3/64 in
- Dimension B
- 4 1/8 in
- Dimension D
- 1 9/16 in
- Dimension H
- 2 3/64 in
- Dimension G
- 31/64 in
- Dimension C
- 9/16 in
- Dimension J
- 4 21/64 in
- Dimension M
- 1 3/16 in
- Dimension A
- 5 3/8 in
- Dimension F
- 19/32 in
- Back Side to Center Width
- 0.828 in
- Mounting Bolt Size
- 9/16 in
- Mount Hole Center-to-Center Height
- 4 1/8 in
- Mount Hole Size
- 5/8 in
- Wire Rope Length
- 5 13/32 in
- Length
- 5 13/32 in
Description
Flange Mount Bearing, Back Side to Center Width 0.828 in, Bearing Insert Material Alloy Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 1/2 in, Bore Type Cylindrical, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Housing Type Square, Included Bearing UCX08-24, Lubricant Material NLGI #2 Equivalent, Maximum Speed 3,800 RPM, Maximum Temperature 220 Degrees F, Minimum Temperature -20 Degrees F, Mount Hole Center-to-Center Height 4 1/8 in, Number of Mount Holes 4
