  6. 5" X 1-1/4" Non-Marking Polyolefin Swivel Caster, No Brake, Loads Up To 300 lb
Shepherd Hardware 5" X 1-1/4" Non-Marking Polyolefin Swivel Caster, No Brake, Loads Up To 300 lb PGS50273ZN-POD01(KK) - main

5" X 1-1/4" Non-Marking Polyolefin Swivel Caster, No Brake, Loads Up To 300 lb

  • Mfr # PGS50273ZN-POD01(KK)

  • Zoro # G7806428

product price:  $25.59
/ea

Key Features

Caster Stem Type
Grip Band
Tread Shape
Standard
Wheel Width
1-1/4 in
Mounting Height
6-1/8 in
Load Rating
300 lb
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PGS50273ZN-POD01(KK)
Zoro #
G7806428
UPC #
-
Country of Origin
China

Dimensions

Wheel Width
1-1/4 in
Mounting Height
6-1/8 in
Stem Length
1-3/8 in
Wheel Dia.
5 in
Stem Dia.
7/16 in
Overall Height
7 1/2 in
Caster Stem Size
7/16 in x 1-3/8 in

Details

Item
Quality Economic Small Equipment Grip Ring Stem Caster
Caster Stem Type
Grip Band
Tread Shape
Standard
Load Rating
300 lb
Load Rating Range
300 to 999 lb
Wheel/Tread Material
Polyolefin
Application
Store Fixtures, Stoage Equipment, Utility Carts, Institutional Equipment, Office Equipment, Food Service, Material Handling Equipment, Hospitality Carts
Non-Marking
Yes
Caster Brake Type
No Brake
Caster Frame Material
Steel
Wheel Bearing Type
Plain Bore (None)
Number of Wheels
1
System of Measurement
Inch
Standards
RoHS Compliant, NSF Approved
Wheel/Tread Color
Black
Caster Mounting Type
Stem
Caster Product Group
Swivel Caster
Swivel Lock Type
No Lock Included
Frame Finish
Zinc Plated
Caster Sub-Type
Swivel
Core Color
Black
Swivel Raceway Type
Double Ball
Series
A-Line
Wheel Core Material
Polyolefin
Operating Temperature Range
-40°F to 160°F
Features
Raceway Dust Cap for Increased Caster Life and Performance, Dual Ball Bearing ­Raceway
Includes Spanner Bushing
No
Wheel Type
Tread on Core
Operating Temperature - Minimum
-40 Degrees F
Number of Mounting Holes
0
For Surface Type
Asphalt, Ceramic, Grease, Oil, Steel
Wheel Core Type
Solid
Wheel Hardness Rating
70 Shore D
Operating Temperature - Maximum
160 Degrees F
Load Capacity - Maximum
300 lb

Description

Stem Caster, Swivel Caster, 300 lb Load Rating, 300 to 999 lb, 5 in Wheel Dia., 1 1/4 in Wheel Width, Polypropylene Wheel/Tread Material, 6 1/8 in Mounting Height, Plain, 7/16 in x 1-3/8 in Caster Stem Size, Friction Ring, Steel Caster Frame Material, Zinc Plated Frame Finish, Yes Non-Marking, 1 Number of Wheels
