  13. Analog monitoring relay Phase sequence m
Siemens Analog monitoring relay Phase sequence m 3UG45112BP20 - main

Analog monitoring relay Phase sequence m

  • Mfr # 3UG45112BP20

  • Zoro # G2052708

product price: $139.99
/ea
Free Shipping & Returns

Key Features

Input or Control Voltage
320 to 500V AC
DC Contact Rating - Relay
0.10A @ 250V, 0.20A @ 125V, 1.00A @ 24V
Mounting - Relay
DIN Rail
Over Voltage
No
Number of Pins - Relay
6
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
3UG45112BP20
Zoro #
G2052708
UPC #
804766187940
Country of Origin
Germany

Dimensions

Body Height - Relay
3.7 in
Body Depth - Relay
3.58 in
Body Width - Relay
0.89 in
Depth
91 millimetre
Width
23 millimetre
Height
94 millimetre
Body Height
4.21 in
Body Width
0.89 in
Body Depth
3.58 in

Details

Item
Relay
Input or Control Voltage
320 to 500V AC
DC Contact Rating - Relay
0.10A @ 250V, 0.20A @ 125V, 1.00A @ 24V
Mounting - Relay
DIN Rail
Over Voltage
No
Number of Pins - Relay
6
Standards
CCC, CE Certified, EAC, RCM, UL Listed
Item - Relay
Phase Monitor Relay
Input Voltage
320 to 500V AC
Restart
Auto
Phase Unbalance
No
Under Voltage
No
IP Rating
IP20
Minimum Switching Current
5 mA
Maximum Switching Current
5 A
Contact Rating (AC)
3 A @ 250/400V
Adjustment Interface
Analog
Mounting Style
Snap-On
Maximum Operating Temperature
140 Degrees F
Contact Rating (DC)
0.10 A @ 250V, 0.20 A @ 125V, 1.00 A @ 24V
Minimum Operating Temperature
-13 Degrees F
Weight
4.59 oz
Mechanical Operating Durability
10,000,000
Frequency
50/60 Hz
Overvoltage
No
Current Rating
5 A
Number of Pins
6
Restart Time Delay
0.1 to 20 sec
Monitored Parameters
Phase Sequence
Electrical Operating Durability
100,000
Base Shape
Square
Number of making contacts
0
min. voltage measuring range
320 volt
Number of changers
2
function over-voltage detection present
No
Max. rated AC voltage for controls, 50 Hz
500 volt
Phase sequence monitoring
Yes
Asymmetry recognition present
No
max. rated AC voltage for controls (60 Hz)
500 volt
min. rated control voltage Us with AC 50 Hz
320 volt
Design of electrical connection
Screw/spring connection
max. voltage measuring range
500 volt
Phase failure recognition possible
No
function undervoltage recognition present
No
Number of breaking contacts
0
Type of actuation
AC
min. rated control voltage Us with AC 60 Hz
320 volt
detachable terminals present
Yes

Description

Relay, Base Shape Square, Contact Rating (AC) 3 A @ 250/400V, Contact Rating (DC) 0.10 A @ 250V, 0.20 A @ 125V, 1.00 A @ 24V, Current Rating 5 A, Input Voltage 320 to 500V AC, Monitored Parameters Phase Sequence, Number of Pins 6, Restart Auto, Restart Time Delay 0.1 to 20 sec, IP Rating IP20, Mounting Style Snap-On, Adjustment Interface Analog, Body Depth 3.58 in, Body Height 4.21 in, Body Width 0.89 in, Electrical Operating Durability 100,000, Frequency 50/60 Hz
