  11. Basic Panel 6AV21232DB030AX0
Siemens Basic Panel 6AV21232DB030AX0 6AV2123-2DB03-0AX0 - main

Basic Panel 6AV21232DB030AX0

  • Mfr # 6AV2123-2DB03-0AX0

  • Zoro # G308131656

product price: $648.99
/ea
Free Shipping & Returns

Key Features

Touch screen present
Yes
Process value provision (input) possible
Yes
number of programmable function keys
4
Number of HW interfaces serial TTY
0
Min. operating temperature
0 degree_Celsius
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6AV2123-2DB03-0AX0
Zoro #
G308131656
UPC #
887621830281
Country of Origin
Germany

Dimensions

Height of front
116 millimetre
Installation depth
33 millimetre
Width of front
141 millimetre

Details

Touch screen present
Yes
Process value provision (input) possible
Yes
number of programmable function keys
4
Number of HW interfaces serial TTY
0
Min. operating temperature
0 degree_Celsius
Display type
TFT
Number of HW interfaces Wireless
0
Number of colors/shades of gray of the display
65536
max. number of pixels, vertical
272
max. number of pixels, horizontal
480
Number of HW interfaces PROFINET
1
numeric keyboard present
Yes
Manufacturer product family
HMI
Supply voltage type
DC
useable project memory/user memory
10000 kilobyte
max. supply voltage with DC
28.8 volt
Number of HW interfaces, other
0
number of buttons with LED
0
Alpha keyboard present
Yes
Manufacturer product root
Basic Panel
Max. operating temperature
50 degree_Celsius
Number of levels, password protection
50
description of product type
KTP400 Basic
wall mounting/direct mounting possible
No
Messaging system (including buffer and acknowledgement) present
Yes
SW interfaces present
No
Pressure output present
No
number of grey scales
0
Process value display (output) possible
Yes
Message display present
Yes
Number of HW interfaces serial RS422
0
Monitor diagonal
4.3 inch
number of system buttons
0
Number of HW interfaces Industrial Ethernet
1
Bearing track assembly possible
No
min. supply voltage with DC
19 volt
Number of HW interfaces serial RS485
0
Display, color present
Yes
Number of HW interfaces parallel
0
Number of HW interfaces serial RS232
0
Degree of protection (IP), front side
IP65

Description

6Av21232Db030Ax0 Basic Panel Simatic Hmi Ktp400 Basic KeyTouch Operation 4 Tft Display 65536 Colors Profinet Interface Configurable From Wincc Basic V13 Step 7 Basic V13 Contains OpenSource Software
