  6. DC Power Supply, 176/550V AC; 85/264V AC, 24V DC, 140 W, 5 A, DIN Rail
Siemens DC Power Supply, 176/550V AC; 85/264V AC, 24V DC, 140 W, 5 A, DIN Rail 6EP13333BA10 - main

DC Power Supply, 176/550V AC; 85/264V AC, 24V DC, 140 W, 5 A, DIN Rail

  • Mfr # 6EP13333BA10

  • Zoro # G0080221

product price:  $330.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
176/550V AC; 85/264V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
140 W
Current - Output
5 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6EP13333BA10
Zoro #
G0080221
UPC #
887621837242
Country of Origin
Romania

Dimensions

Overall Height
2-3/4 in
Overall Width
4.92 in
Overall Depth
4.76 in
Depth
4.76 in
Width
2-3/4 in
Height
4.92 in

Details

Item
DC Power Supply
Input Voltage
176/550V AC; 85/264V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
140 W
Current - Output
5 A
Mounting
DIN Rail
Housing Material
Metal
Phase
Single
Power Supply Style
Switching
Output Voltage
24V DC
Series
SITOP
Peak Amps
15
Status Indicator
LED
Hz
50/60 Hz
IP Rating
IP20
Case Material
Metal Case
Operating Temp. Range
-25 to 70°C
Power Rating
140W
Hold Up Time
25 msec
Style
Switching
Standards
BIS, CB-Certificate Yes, CE, CSA, EAC, RCM, REACH Art. 33, RoHS, UL, WEEE (2012/19/EU)
Phase - Electrical
Single
Output Amps
5A
Output Noise
50mV
Connection
Screw
Regulated / Unregulated
Regulated
Protection
Short-Circuit Proof
Current - Peak
15 A
Operating Temperature - Maximum
158 Degrees F
Input Frequency - Nominal
50/60 Hz
Wire Connection Type
Screw Terminals
Special Features
Overvoltage Protection, Short Circuit Protection
Operating Temperature - Minimum
-13 Degrees F
Current - Inrush
35 A

Description

DC Power Supply, Input Voltage 120 to 500 V AC, Output Voltage 24V DC, Power Rating 140W, Output Amps 5, Mounting DIN Rail, Switching, Case Material Metal Case, Height 4.92 in, Width 2.75 in, Depth 4.76 in, Series SITOP, Hz 50 to 60 Hz, Phase - Electrical Single, Peak Amps 15, IP Rating IP20, Output Noise 50mV, Hold Up Time 25 msec, Status Indicator LED, Operating Temp. Range -25 Degrees to 70 Degrees C
