Siemens DC to DC Converter, 600V DC to 24V DC, 480VA, 0 Hz, DIN Rail 6EP15363AA00 - main

DC to DC Converter, 600V DC to 24V DC, 480VA, 0 Hz, DIN Rail

  • Mfr # 6EP15363AA00

  • Zoro # G8364168

product price: $847.99
/ea
Free Shipping & Returns

Key Features

Converts
600V DC to 24V DC
VA Rating
480VA
Mounting
DIN Rail
Frequency
0 Hz
Height
125 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6EP15363AA00
Zoro #
G8364168
UPC #
040892854770
Country of Origin
Romania

Dimensions

Height
125 mm
Width
90 mm
Depth
125 mm

Details

Item
DC to DC Converter
Converts
600V DC to 24V DC
VA Rating
480VA
Mounting
DIN Rail
Frequency
0 Hz
IP Rating
IP20
Status Indicator
LED
Operating Temp. Range
-25 Degrees C to 70 Degrees C
Features
Built-in Incoming Fuse, Parallel Switching for Enhanced Performance, Primary/Secondary Isolation, Product Feature of the Enclosure Housing for Side-by-Side Mounting, Product Function Output Voltage Adjustable, Property of the Output Short-Circuit Proof, Screw-Type Terminals
Input Voltage
600V DC
Output Amps
20
Connection
Screw
Standards
CB-Certificate Yes, CE, CSA, EAC, RCM, REACH Art. 33, RoHS, UL, WEEE (2012/19/EU)
Protection
Short-Circuit Proof
Output Voltage
24V DC
Series
SITOP PSU400M
Regulated / Unregulated
Regulated
Current - Output
20 A
Wire Connection Type
Screw Terminals
Power Supply Style
Switching
Output Voltage - Maximum
28.8 V DC
Housing Material
Metal
Output Voltage - Nominal
24 V DC
Operating Temperature - Maximum
158 Degrees F
Output Voltage - Minimum
24 V DC
Current - Inrush
8 A
Special Features
Short Circuit Protection
Operating Temperature - Minimum
-13 Degrees F
Output Power - Rated
480 W

Description

Stabilized Power Supply, Input Voltage 600V DC, Output Voltage 24V DC, Power Rating 480W, Output Amps 20, Mounting DIN Rail, Height 125 mm, Width 90 mm, Depth 125 mm, Series SITOP PSU400M, IP Rating IP20, Status Indicator LED
