  13. Definite Purpose Magnetic Contactor, 440V-480V AC, 1 P, Non-Reversing, 3 Phase, Screw
Siemens Definite Purpose Magnetic Contactor, 440V-480V AC, 1 P, Non-Reversing, 3 Phase, Screw 45EG10AHA - main

Definite Purpose Magnetic Contactor, 440V-480V AC, 1 P, Non-Reversing, 3 Phase, Screw

  • Mfr # 45EG10AHA

  • Zoro # G8359268

product price: $55.96
/ea

Key Features

Coil Voltage
440V-480V AC
Series
45EG
Number of Poles
1
Reversing Capability
Non-Reversing
Full Load Current - Resistive
40 A
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
45EG10AHA
Zoro #
G8359268
UPC #
804766910845
Country of Origin
China

Dimensions

Depth
2.46 in
Height
3.19 in
Width
1.97 in
Overall Width
1.97 in
Mounting Hole Distance - Height
1.77 in
Overall Depth
2.46 in
Overall Height
3.19 in
Mounting Hole Distance - Width
1.61 in

Details

Item
Definite Purpose Magnetic Contactor
Coil Voltage
440V-480V AC
Series
45EG
Number of Poles
1
Reversing Capability
Non-Reversing
Full Load Current - Resistive
40 A
Full Load Current - Inductive
30 A
Phase
3
Terminal Connection Type
Screw
Standards
REACH Art 33
Reversing
No
Enclosure NEMA Rating
No Enclosure
Horsepower @ Single Phase - 120V AC
2 hp
Mounting Postion
Vertical
Number of Normally Open Main Contacts
1
Contact Material
Silver Cadmium Oxide
Number of Normally Closed Main Contacts
0
Frequency
50/60 Hz
Includes Shunt
Single Pole with Shunt
NEMA Enclosure Rating
No Enclosure
Horsepower @ Three Phase - 240V AC
7 1/2 hp
Mechanical Operating Durability
250,000
Horsepower @ Three Phase - 600V AC
Not Rated
Resistance Properties
Weld Resistant
Mounting Style
Surface
Maximum Voltage Rating
600V AC
Auxiliary Contact Module Capacity
0
Locked Rotor Load
180 A @ 240V, 180 A @ 277V
Maximum Operating Temperature
158 Degrees F
Horsepower @ Single Phase - 240V AC
3 hp

Description

Definite Purpose Magnetic Contactor, LED Lighting Current Rating Not Applicable, Coil Voltage 380-440/440-480V AC, Series 42 Series, Number of Poles 1, NEMA Enclosure Rating No Enclosure, Tungsten Lighting Current Rating Not Applicable, Fluorescent Lighting Current Rating Not Applicable, Reversing Capability Non-Reversing, Frame Size Not Applicable, Horsepower @ Single Phase - 240V AC 3 hp, Horsepower @ Single Phase - 120V AC 2 hp, Full Load Current - Resistive 40 A

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
