Shop SIEMENS

Definite Purpose Magnetic Contactor, 440V-480V AC, 2 P, Non-Reversing, 3 Phase, Screw

  • Mfr # 45EG20AH

  • Zoro # G8363312

product price:  $67.59
/ea

Key Features

Coil Voltage
440V-480V AC
Series
45EG
Number of Poles
2
Reversing Capability
Non-Reversing
Full Load Current - Resistive
40 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
45EG20AH
Zoro #
G8363312
UPC #
783087165519
Country of Origin
China

Dimensions

Width
1.97 in
Depth
2.46 in
Height
3.19 in
Mounting Hole Distance - Width
1.61 in
Overall Height
3.19 in
Mounting Hole Distance - Height
1.77 in
Overall Width
1.97 in
Overall Depth
2.46 in

Details

Item
Definite Purpose Magnetic Contactor
Coil Voltage
440V-480V AC
Series
45EG
Number of Poles
2
Reversing Capability
Non-Reversing
Full Load Current - Resistive
40 A
Full Load Current - Inductive
30 A
Phase
3
Terminal Connection Type
Screw
Enclosure NEMA Rating
No Enclosure
Standards
REACH Art 33
Reversing
No
Auxiliary Contact Module Capacity
0
Number of Normally Closed Main Contacts
0
NEMA Enclosure Rating
No Enclosure
Mechanical Operating Durability
250,000
Horsepower @ Single Phase - 120V AC
2 hp
Mounting Style
Surface
Contact Material
Silver Cadmium Oxide
Horsepower @ Three Phase - 600V AC
Not Rated
Resistance Properties
Weld Resistant
Horsepower @ Single Phase - 240V AC
3 hp
Horsepower @ Three Phase - 240V AC
7 1/2 hp
Locked Rotor Load
180 A @ 240V, 180 A @ 277V
Mounting Postion
Vertical
Maximum Voltage Rating
600V AC
Frequency
50/60 Hz
Number of Normally Open Main Contacts
2
Maximum Operating Temperature
158 Degrees F
Contactor Style
HVACR Definite Purpose Contactor

Description

Definite Purpose Magnetic Contactor, LED Lighting Current Rating Not Applicable, Coil Voltage 380-440/440-480V AC, Series 42 Series, Number of Poles 2, NEMA Enclosure Rating No Enclosure, Tungsten Lighting Current Rating Not Applicable, Fluorescent Lighting Current Rating Not Applicable, Reversing Capability Non-Reversing, Frame Size Not Applicable, Horsepower @ Single Phase - 240V AC 3 hp, Horsepower @ Single Phase - 120V AC 2 hp, Full Load Current - Resistive 40 A

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
