  11. Digital Output Module 6ES71326BF010BA0
Siemens Digital Output Module 6ES71326BF010BA0 6ES7132-6BF01-0BA0 - main

Digital Output Module 6ES71326BF010BA0

  • Mfr # 6ES7132-6BF01-0BA0

  • Zoro # G108092317

product price: $132.99
/ea
Free Shipping & Returns

Key Features

Height
73 millimetre
Width
15 millimetre
Depth
58 millimetre
digital outputs, configurable
Yes
Number of HW interfaces parallel
0
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6ES7132-6BF01-0BA0
Zoro #
G108092317
UPC #
804766529023
Country of Origin
Germany

Dimensions

Height
73 millimetre
Width
15 millimetre
Depth
58 millimetre

Details

digital outputs, configurable
Yes
Number of HW interfaces parallel
0
Functional safety (SIL)
SIL 2
Manufacturer product family
ET 200SP
max. supply voltage with DC
28.8 volt
Number of outputs, digital
8
Number of HW interfaces Wireless
0
Number of HW interfaces PROFINET
0
Front installation possible
No
Protection type IP
IP20
Min. delay time with change of signal
0 millisecond
Number of HW interfaces Industrial Ethernet
0
Field bus connection possible via separate bus couplers
Yes
Output current
1 ampere
Number of HW interfaces serial RS485
0
Explosion protection categories for gases
ATEX gas-ex-protection, Cat. 3
Design of digital output
Transistor
Supply voltage type
DC
Number of inputs, digital
0
Number of HW interfaces serial RS422
0
Bearing track assembly possible
Yes
min. supply voltage with DC
19 volt
Performance level acc. to EN ISO 13849-1
D
Short circuit protection, outputs present
Yes
Max. perm. voltage
29 volt
System components present
Yes
Number of HW interfaces serial TTY
0
Max. delay time with change of signal
0 millisecond
Rack-assembly possible
No
Output voltage type
DC
min. permissible voltage at output
19 volt
description of product type
DQ 8x24VDC/0.5A ST
Number of HW interfaces serial RS232
0
Optical interface present
No
wall mounting/direct mounting possible
No
Power loss, static, current-independent [Pls]
1 watt
Number of inputs
0
Manufacturer product root
Digital module output
Number of outputs
8
Number of HW interfaces, other
0

Description

6Es71326Bf010Ba0 Digital Output Module 05Amp 8X24Vdc Fits To BuType A0 Colour Code Cc02 Module Diagnostics For ShortCircuit To L And Ground Wire Break Supply Voltage
