Siemens Input Module 6ES71366RA000BF0 6ES7136-6RA00-0BF0 - main

Input Module 6ES71366RA000BF0

  • Mfr # 6ES7136-6RA00-0BF0

  • Zoro # G408092277

product price: $219.99
/ea
Free Shipping & Returns

Key Features

Depth
58 millimetre
Width
20 millimetre
Height
73 millimetre
min. permissible voltage at output
20 volt
Supply voltage type
DC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6ES7136-6RA00-0BF0
Zoro #
G408092277
UPC #
887621782665
Country of Origin
Germany

Dimensions

Depth
58 millimetre
Width
20 millimetre
Height
73 millimetre

Details

min. permissible voltage at output
20 volt
Supply voltage type
DC
Manufacturer product family
ET 200SP
digital outputs, configurable
Yes
Power loss, static, current-independent [Pls]
1 watt
Optical interface present
No
description of product type
F-RQ 24 to 48VDC/24 to 230VAC/5A ST
Max. perm. voltage
264 volt
Manufacturer product root
Digital module output
Number of HW interfaces serial RS422
0
Number of HW interfaces serial RS232
0
Design of digital output
Relay
System components present
Yes
Number of inputs
0
Bearing track assembly possible
Yes
Number of HW interfaces PROFINET
0
Number of HW interfaces parallel
0
Number of HW interfaces serial TTY
0
Functional safety (SIL)
SIL 3
Number of outputs
1
Performance level acc. to EN ISO 13849-1
E
Number of HW interfaces, other
0
Output voltage type
AC/DC
wall mounting/direct mounting possible
No
Front installation possible
No
Number of HW interfaces Industrial Ethernet
0
Number of HW interfaces serial RS485
0
Number of outputs, digital
1
Rack-assembly possible
No
Field bus connection possible via separate bus couplers
Yes
Number of inputs, digital
0
max. supply voltage with DC
28.8 volt
Protection type IP
IP20
Number of HW interfaces Wireless
0
min. supply voltage with DC
20 volt

Description

6Es71366Ra000Bf0 Input Module Simatic Dp Electron Module For Et200Sp 1 FRq St Dc24VAc230V5A 20Mm Width 1 Relay Output 2 NoContacts Total Output Current 5A Rated Voltage Dc24V And Ac24 230V
