Miniature Circuit Breaker, BFH Series, 15A, 1 Pole, 120V AC, 22kA at 120V AC
Mfr # BF115H
Zoro # G0570385
product price:Â $794.99
/ea
Free Shipping & Returns
Key Features
Series
BFH
Amps
15A
Number of Poles
1
AC Voltage Rating
120V AC
Circuit Breaker Type
Ground Fault Circuit Interrupter
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- BF115H
- Zoro #
- G0570385
- UPC #
- 783643069596
- Country of Origin
- Philippines
Dimensions
- Frame Size
- 60A/BLHF
- Width
- 4 in
- Depth
- 5 in
- Height
- 1 in
- Max. Wire Size
- 10 AWG
- Min. Wire Size
- 12 AWG (Al), 14 AWG (Cu)
- Length
- 1 in
Details
- Item
- Miniature Circuit Breaker
- Series
- BFH
- Amps
- 15A
- Number of Poles
- 1
- AC Voltage Rating
- 120V AC
- Circuit Breaker Type
- Ground Fault Circuit Interrupter
- Phase
- 1
- Circuit Breaker Actuator
- Toggle
- Circuit Breaker Mounting Style
- Bolt On
- Max. AIR Rating
- 22kA at 120V AC
- Terminal Connection
- Lugs
- DC Voltage Rating
- Not Rated
- For Use With
- Siemens Panelboards
- Standards
- CSA Certified, HACR Rated, NOM Certified, UL Listed
- Voltage
- 120VAC
Description
Miniature Circuit Breaker, Amps 15 A, AC Voltage Rating 120V AC, Circuit Breaker Type Ground Fault Circuit Interrupter, Number of Poles 1, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Phase Single, Series BFH, Max. AIR Rating 22kA at 120V AC, For Use With Siemens Panelboards, Terminal Connection Lug, Frame Size 60A/BLHF, Length 1 in, Width 4 in, Depth 5 in, Min. Wire Size 12 AWG (Al), 14 AWG (Cu), Max. Wire Size 10 AWG
