Silverthin Bearing Slewing Ring Bearing, Carbon Steel STE-265 - main

Slewing Ring Bearing, Carbon Steel

  • Mfr # STE-265

  • Zoro # G2008907

product price: $4,163.99
/ea
Free Shipping & Returns

Key Features

Material
Carbon Steel
Series
STE
Weight
57 lb
Pitch
5/9
Outside Dia.
17.086 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
STE-265
Zoro #
G2008907
UPC #
815228023454
Country of Origin
China

Dimensions

Outside Dia.
17.086 in
Width
1.968 in
Inside Mounting Hole Size
0.562 in
Outside Mounting Hole Size
0.562 in
Inside Dia.
10.433 in
Outside Diameter
17.086 in
Inside Mount Hole Size
0.562 in
Outside Mount Hole Size
0.562 in
Overall Width
1.968 in
Bore Diameter
10.433 in

Details

Item
Slewing Ring Bearing
Material
Carbon Steel
Series
STE
Weight
57 lb
Pitch
5/9
Max. Temp.
140 Degrees F
Number of Inside Mounting Holes
24
Moment Rating
40,940 ft-lb
Application
Capstans and Turnstiles, Conveyors, Displays, Light Duty Aerial Platforms, Light Duty Hand Operated Mechanism, Light Duty Index Table, Light Duty Medical Devices, Light or Medium Duty Industrial Manipulator or Robot, Rotary Tables, Rotating Signs, Scrap Yard Construction, Tire-Mounted Light Duty Construction, Track-Mounted Light Duty Construction, Wastewater Treatment, Welding Positioners
Number of Outside Mounting Holes
18
Seal Type
Non-Contact
Number of Teeth
84
Pressure Angle
20 Degrees
Outside Mounting Hole Type
Thru-Hole
Gear Type
External
Inside Mounting Hole Type
Thru-Hole
Housing Material
Carbon Steel
Bearing Type
Single Row Ball
Maximum Temperature
140 Degrees F
Inside Mount Hole Type
Thru-Hole
Number of Gear Teeth
84
Rolling Element Rows
1
Outside Mount Hole Type
Thru-Hole
Number of Inside Mount Holes
24
Bearing Insert Type
4-Point Angular Contact Ball
Gear Tooth Load Capacity
7,330 lb
System of Measurement
Inch
Seal Material
Buna-N
Minimum Temperature
-40 Degrees F
Closure
Sealed
Diametral Pitch
5/7
Number of Outside Mount Holes
18
Standards
AGMA 8

Description

Slewing Ring Bearing, Bore Diameter 10.433 in, Moment Rating 40,940 ft-lb, Outside Diameter 17.086 in, Overall Width 1.968 in, Seal Type Non-Contact, System of Measurement Inch, Gear Type External
