Silverthin Bearing Slewing Ring Bearing, Carbon Steel STO-050 - main

Slewing Ring Bearing, Carbon Steel

  • Mfr # STO-050

  • Zoro # G2008889

product price: $758.99
/ea
Free Shipping & Returns

Key Features

Material
Carbon Steel
Housing Material
Carbon Steel
Outside Mounting Hole Size
0.260 in
Application
Capstans and Turnstiles, Conveyors, Displays, Light Duty Aerial Platforms, Light Duty Hand Operated Mechanism, Light Duty Index Table, Light Duty Medical Devices, Light or Medium Duty Industrial Manipulator or Robot, Rotary Tables, Rotating Signs, Scrap Yard Construction, Tire-Mounted Light Duty Construction, Track-Mounted Light Duty Construction, Wastewater Treatment, Welding Positioners
Max. Temp.
140 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
STO-050
Zoro #
G2008889
UPC #
815228023621
Country of Origin
China

Dimensions

Outside Mounting Hole Size
0.260 in
Inside Dia.
1.968 in
Outside Dia.
4.331 in
Width
0.787 in
Inside Mounting Hole Size
0.260 in
Inside Mount Hole Size
0.26 in
Outside Diameter
4.331 in
Outside Mount Hole Size
0.26 in
Overall Width
0.787 in
Bore Diameter
1.968 in

Details

Item
Slewing Ring Bearing
Material
Carbon Steel
Housing Material
Carbon Steel
Application
Capstans and Turnstiles, Conveyors, Displays, Light Duty Aerial Platforms, Light Duty Hand Operated Mechanism, Light Duty Index Table, Light Duty Medical Devices, Light or Medium Duty Industrial Manipulator or Robot, Rotary Tables, Rotating Signs, Scrap Yard Construction, Tire-Mounted Light Duty Construction, Track-Mounted Light Duty Construction, Wastewater Treatment, Welding Positioners
Max. Temp.
140 Degrees F
Moment Rating
515 ft-lb
Series
STO
Inside Mounting Hole Type
Thru-Hole
Outside Mounting Hole Type
Thru-Hole
Number of Outside Mounting Holes
8
Seal Type
Non-Contact
Bearing Type
Single Row Ball
Number of Inside Mounting Holes
8
Weight
2 lb
Gear Type
No Gear
Minimum Temperature
-40 Degrees F
Inside Mount Hole Type
Thru-Hole
Number of Outside Mount Holes
8
Outside Mount Hole Type
Thru-Hole
Number of Inside Mount Holes
8
Maximum Temperature
140 Degrees F
Seal Material
Buna-N
Bearing Insert Type
4-Point Angular Contact Ball
System of Measurement
Inch
Closure
Sealed
Rolling Element Rows
1

Description

Slewing Ring Bearing, Bore Diameter 1.968 in, Moment Rating 515 ft-lb, Outside Diameter 4.331 in, Overall Width 0.787 in, Seal Type Non-Contact, System of Measurement Inch, Gear Type No Gear
